KEMET R82 Film Capacitor Through Hole, 22 nF ±10%, 400 V DC, 200 V AC Radial Lead, 5 mm Pitch R82MC2220Z350K

KEMET R82MC2220Z350K is a high-quality film capacitor with a capacitance of 22 nF and a capacitance tolerance of ±10%. This through hole radial lead capacitor is rated for 400 V DC and 200 V AC, providing robust electrical performance for various industrial and automotive electronic applications.

Constructed using metallized polyester film which can be either wound or stacked, the capacitor ensures stable capacitance and self-healing properties. Electrical connections are established through radial tinned wire leads welded directly to the capacitor winding ends, all encapsulated within thermosetting resin to provide mechanical and environmental protection.

This film capacitor features a lead pitch of 5 mm, lead length of 17 mm, and lead diameter of 0.5 mm, facilitating secure and reliable PCB mounting. It operates efficiently across a wide temperature range from -55°C to 105°C, making it suitable for harsh environmental conditions.

Standard compliance includes RoHS for environmental safety, IEC 60384-2 for capacitor safety & performance, and automotive-grade AEC-Q200, qualifying it for demanding automotive electronics use.

Key use cases involve coupling, bypassing, blocking, timing, and decoupling circuits in industrial, automotive, and other electrical assemblies. The compact form factor (7.2 mm length, 4.5 mm width, 9.5 mm height) supports space-efficient PCB designs.

Packaged in bags for convenient handling and storage, the R82 series supports capacitance ranges from 0.001 μF up to 4.7 μF and voltage ratings from 50 V DC up to 400 V DC, with capacitance tolerances ±5%, ±10%, and ±20% available as per variant.

Constructed with metallized polyester film using wound or stacked technology. Designed with radial leads electrically welded to capacitor winding ends. Encapsulated in thermosetting resin for durability. Operating temperature range from -55°C to +105°C.

Compliant with RoHS, IEC 60384-2, and AEC-Q200 standards. Lead pitch of 5 mm with radial tinned wire leads. Applications including coupling, bypassing, blocking, timing, and decoupling. Compact dimensions suited for PCB mounting.
