KEMET R75L Film Capacitor, ±10 % Tolerance, 330 nF Capacitance, 560 V DC, 250 V AC, Through Hole Mount R75LI33304000K

The KEMET R75LI33304000K Film Capacitor is part of the R75L series, engineered using metallized polypropylene film technology which ensures stable electrical performance and long-term reliability. This capacitor features radial leads that are electrically welded to the metal layer on each end of the winding and encapsulated within a self-extinguishing, solvent-resistant plastic case made with thermosetting resin material to withstand harsh industrial conditions.

With a capacitance of 330 nF and tolerance at ±10 %, it is rated for 560 V DC continuous voltage and 250 V AC voltage, complying with stringent automotive standards such as AEC-Q100. The device operates effectively in temperature extremes from -55°C to +105°C, making it suitable for a wide range of applications including power supplies, electronic filters, and high frequency circuits.

The designed lead pitch is 15 mm with radial lead types to facilitate through-hole mounting on printed circuit boards. The product aligns with RoHS directives and IEC 60286-2 standards ensuring environmental compliance and product safety.

This capacitor exhibits a low dissipation factor between 0.05 % and 0.08 %, indicating exceptional efficiency with minimal energy loss. The robust build with a lead length of 30 mm and lead diameter of 0.8 mm supports reliable mechanical and electrical connections during assembly.

Typically packaged in bags, the unit is convenient for bulk usage in manufacturing or repair operations. The R75 series offers a broad capacitance range from 220 pF up to 33 μF with voltage ratings extending to 2000 VD, providing versatile choices for various electronic design demands.

Constructed with metallized polypropylene film for excellent reliability and performance. Encased in a flame-retardant, solvent-resistant plastic housing for enhanced durability. Radial tinned wire leads ensure strong electrical connections and easy through-hole PCB mounting.

Wide operating temperature range from -55°C to +105°C suits diverse industrial applications. Capacitance tolerance available in ±5 %, ±10 %, and ±20 % for varied precision needs. Compliance with RoHS and IEC standards confirms quality and regulatory adherence.

Low energy dissipation factor enhances efficiency, reducing power losses. Lead specifications optimized for reliable assembly and mechanical robustness. Versatile capacitance and voltage ranges usable for numerous electronic systems.

Packaged conveniently in bags for bulk handling and inventory management.

This Film Capacitor is ideal for use in industrial electronics, power supplies, automotive electronics, and consumer devices requiring high frequency and high voltage performance. Suitable for applications demanding stability and compliance in harsh environments, the R75L series supports innovation and reliable electronic design.
