Cosel DC/DC Converter 15V DC, -15V DC, 100 mA Output, 24V DC Input, 3W PCB Mount MGFW32415

Cosel MGFW32415 DC/DC Converter is a compact and efficient power supply module offering 3 watts of output power. It provides dual outputs of 15V DC and -15V DC at 100 mA each, making it suitable for applications requiring bipolar power supply configurations. This converter supports a wide input voltage range from 9V to 24V DC, with surge voltage handling capability up to 50V DC, ensuring stable performance in varying electrical conditions.

The product’s SIP-6 package form factor and compact dimensions (17mm length, 8.5mm width, and 12mm depth) facilitate easy mounting on printed circuit boards (PCB). Its lightweight design at 4 grams promotes integration into compact electronic devices and assemblies without adding excessive mass.

MGFW32415 model achieves a high efficiency of 82%, reducing heat dissipation and improving energy savings in industrial, laboratory, and commercial electronic systems. With an isolation voltage rating of 1000 V DC, the converter delivers electrical isolation between input and output, enhancing operator safety and minimizing noise transfer to sensitive circuitry.

Designed with overcurrent protection that automatically resets, the converter ensures dependable and safe operation in mission-critical applications. It operates reliably within a wide temperature range from -40°C minimum to 85°C maximum, making it suitable for harsh environmental conditions typically encountered in industrial settings.

Its 5-pin mount type eases installation and electrical connectivity on PCB layouts, supporting efficient system design. The unit complies with multiple international safety and certification standards including EN62368-1, C-UL, CE, CSA, RoHS, UL62368-1, UL60950-1, and UKCA, ensuring adherence to global quality and regulatory requirements.

This compact DC/DC converter is ideal for use in power supply and distribution systems, industrial electronics, and precision instrumentation where stable, isolated dual output voltages are necessary. Its design supports modern electronics manufacturing demands while delivering consistent electrical performance.

Operates with input voltage range from 9V to 24V DC for versatile applications. Dual output voltage with 100 mA current supports dual polarity power supplies. Compact SIP-6 package with small dimensions: 17mm length, 8.5mm width, 12mm depth.

High efficiency of 82% ensures minimal power loss during operation. Isolation voltage rated at 1kV DC for safety and noise reduction. Reliable operation with built-in overcurrent protection that auto-recovers. Wide operating temperature range from -40°C to +85°C for industrial environments.

Five-pin PCB mount configuration simplifies integration into electronic assemblies. Lightweight design weighing only 4 grams for compact electronics. Compliance with international standards including EN62368-1, C-UL, CE, CSA, RoHS, and UKCA.
