Cosel DC/DC Converter, 12 V dc, -12 V dc, 420 mA Output, 24 V dc Input, 18 V Input, 10.08 W Power, PCB Mount Type MGW102412

Cosel MGW102412 DC/DC Converter is designed for reliable and efficient power conversion applications, delivering dual output voltages of 12 V dc and -12 V dc at 420 mA output current. It accepts a wide input voltage range of 18 V to 24 V dc, making it adaptable to various power supply conditions. This converter is housed in a SIP-8 package with 7 pins and PCB mount type, ideal for compact electronic devices that require stable regulated power.

The device offers a maximum output power of 10.08 W and maintains an efficiency of approximately 87%, improving energy usage while reducing thermal stress. It features a high isolation voltage of 1 kV dc to ensure electrical safety and robustness in demanding industrial and commercial environments.

Operating temperature ranges from -40 °C to 85 °C, allowing deployment in harsh or varying climatic conditions typical in industrial instrumentation, communications, and control systems. The converter’s ripple and noise are controlled at 600 mV peak-to-peak, suitable for sensitive electronic circuits.

With compact dimensions (22 mm length, 9.5 mm width, and 12 mm depth) and a lightweight of 7 grams, the MGW102412 is a perfect component for PCB integration in power supplies and voltage conversion modules.

The product is compliant with international safety and performance standards such as EN62368-1, UL60950-1, RoHS, CSA, cUL, CE, and UKCA, providing assured quality and reliability.

Typical applications include industrial control units, telecommunications equipment, embedded systems power regulation, and other electronic control instrumentation needing dual output DC voltage.

Supports wide input voltage range from 18 V to 24 V dc ensuring operational versatility. Maximum output power rating of 10.08 W suitable for embedded PCB power applications. PCB mountable SIP-8 package with 7 pins enables compact integration into electronic designs.

Built-in protections including overcurrent and high isolation voltage of 1 kV dc enhance device reliability and safety. High efficiency around 87% optimizes power usage and reduces heat generation. Operates reliably within temperature range from -40 °C to 85 °C for varied environments.

Compact dimensions of 22 mm length, 9.5 mm width and 12 mm depth facilitate space-saving PCB layouts. Certifications include EN62368-1, UL60950-1, RoHS, CSA, UL62368-1, cUL, CE, UKCA ensuring compliance to international standards.
