JST PSI Series Straight Through Hole PCB Header, 5 Contacts, 4 mm Pitch, 1 Row, Shrouded B05B-PSILE-1(LF)(SN)

JST B05B-PSILE-1(LF)(SN) is a high-quality PSI Series straight through hole PCB header designed for electronic applications requiring secure wire-to-board connections. This model features 5 contacts arranged in a single row with a 4 mm pitch, ideal for precise PCB layout requirements.

The connector is fully shrouded with a locking mechanism, ensuring secure mating and preventing accidental disconnections. Colour-coded keying and notches on the single-row header prevent misalignment and mismating during installation, enhancing system reliability. The housing is made from fibreglass reinforced polybutylene terephthalate, providing mechanical strength and heat resistance.

Contacts are manufactured from copper alloy and plated with tin, offering excellent electrical conductivity and corrosion resistance. This PCB header supports a current rating of 12A and a voltage rating of 300V, suitable for many industrial electronic devices.

The mounting style is through hole with solder termination, providing sturdy mechanical and electrical connection to the PCB. PCB pegs integrated into the housing facilitate exact positioning and improved stability on the board.

Operating temperature ranges from -25°C to 85°C, allowing usage in diverse environmental conditions. The male contact gender and straight orientation make it compatible with standard wire-to-board setups.

Features a locking mechanism for secure mating connection. Includes keying and colour coding to prevent mismating and misalignment. Constructed with fibreglass reinforced polybutylene terephthalate housing for durability.

Contacts made of copper alloy with tin plating for reliable conductivity. Capable of handling up to 12A current and 300V voltage. Designed with PCB pegs for positioning and extra stability on the PCB. Operates reliably within temperature range of -25°C to 85°C.

Connector system supports solder termination and through-hole mounting.

This PCB header is well-suited for industrial, electronic manufacturing, and laboratory applications where robust and reliable wire-to-board connections are critical. Its technical features deliver dependable performance in electronic devices, power supply assemblies, and various automated machinery systems.
