Norcomp SEAL-D 26 Way Straight 2.286 mm Pitch Plug-in D-Sub Connector Female 780-M26-203L001
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV |
| Brand | Norcomp |
| Orientation | Straight |
| Current | 5A |
| Model | 780-M26-203L001 |
| Mount Type | Plug-in |
| Housing Material | Steel |
| Contact Material | Brass |
| Series | 780, SEAL-D |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.286mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | High Density |
Key Features
- Features 26 contacts with gold-plated brass contacts for reliable conductivity.
- Steel housing for durability and improved shielding performance.
- Supports a voltage of 1 kV and temperature range from -55°C to 105°C.
- Solder termination type with female connector and plug-in mount.
- Meets IEC-529-IP67 sealing requirements for outdoor and harsh environment protection.
- Nickel plated steel shell provides excellent grounding and retention.
- Designed for industrial, medical, and consumer electronics applications requiring robust connectors.
- Standard D-sub profile enabling easy integration without enclosure or PCB redesign.
Product Description
Norcomp 780-M26-203L001 SEAL-D 26 Way Straight 2.286 mm Pitch Plug-in D-Sub Connector Female is a high-density, IP67 sealed D-Sub connector designed to withstand harsh environmental conditions. Rated for 5A current and 1 kV voltage, this connector features gold-plated brass contacts with screw machined reliability encapsulated in a nickel-plated steel shell for enhanced shielding and grounding.
The SEAL-D series connectors maintain the same physical footprint as standard D-Sub connectors, making them ideal for upgrading to IP66/67 protection without redesigning enclosures or PCBs. The solder termination type and female plug-in configuration ensure reliable connection and ease of installation.
Operating in temperatures from -55°C to 105°C, these connectors are suitable for outdoor and industrial applications including handheld computing devices, remote sensors, data loggers, industrial and medical equipment, and a wide range of consumer and commercial electronics.
The nickel plated steel shell includes ground indents for improved shielding and retention. The SEAL-D 780 and 781 series also offer additional retention features such as board locks and locator plates in right-angle versions, ensuring secure PCB mounting.
Available in the industry-standard sizes of 15, 26, and 44 positions, these connectors are part of Norcomp's SEAL-D series designed for robust and reliable performance in challenging environments. Panel sealing kits are sold separately for enhanced sealing solutions.
Features 26 contacts with gold-plated brass contacts for reliable conductivity. Steel housing for durability and improved shielding performance. Supports a voltage of 1 kV and temperature range from -55°C to 105°C. Solder termination type with female connector and plug-in mount.
Meets IEC-529-IP67 sealing requirements for outdoor and harsh environment protection. Nickel plated steel shell provides excellent grounding and retention. Designed for industrial, medical, and consumer electronics applications requiring robust connectors.
Standard D-sub profile enabling easy integration without enclosure or PCB redesign. Ideal for handheld computers, sensors, transmitters, emergency beacons, and more. Maintains compatibility with industry standard 15, 26, and 44 position sizes.
Explore more Norcomp D-Sub Connectors in the Electronics & Electricals category at EnvMart for reliable connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage rating of 1 kV.
It operates within a temperature range from -55°C to 105°C.
This connector features 26 contacts.
The contacts are made of brass with gold plating, and the housing is constructed from steel.
It utilizes a solder termination type.
Yes, it meets IEC-529-IP67 sealing requirements, making it suitable for outdoor and harsh environments.
The current rating for this model is 5A.
Yes, it maintains compatibility with industry-standard sizes of 15, 26, and 44 positions.
It is designed for industrial, medical, and consumer electronics applications, including handheld computing devices and remote sensors.
The pitch size is 2.286 mm.
The nickel-plated steel shell provides excellent grounding and retention, enhancing shielding performance.
This model supports a plug-in mount type.
