Panasonic PCB Power Relay 24V DC Coil 20A Switching Current DPST HEV2AN-P-DC24V
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 39.4mm |
| Length | 50mm |
| Model | HEV2AN-P-DC24V |
| Width | 41mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HE-V |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 20A |
| Contact arrangement | 2 Form A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | cULus, VDE |
| Coil Resistance | 300Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 1kV dc |
| Switching AC Voltage | 1kV ac |
| Coil Power | 1.92W |
Key Features
- The relay is compact in size and designed for printed circuit board mounting.
- It operates reliably over a temperature range from -40°C to 85°C.
- The contact material is made of high-quality silver alloy ensuring low contact resistance.
- Coil resistance is rated at 300 ohms with coil power consumption of 1.92W.
- Suitable for high voltage switching up to 1kV DC and 1kV AC.
- The relay offers a contact arrangement of 2 Form A for efficient double-pole switching.
- It conforms to recognized standards including cULus and VDE for safe industrial use.
- Manufactured in Japan, assuring quality and durability.
Product Description
Panasonic HEV2AN-P-DC24V PCB Power Relay provides reliable switching with a 24V DC coil and 20A maximum switching current in a DPST configuration. Designed for PCB mounting, it occupies a compact footprint of 50mm length, 41mm width, and 39.4mm height, making it ideal for space-conscious industrial and automation applications.
The relay operates under wide temperature conditions (-40°C to 85°C) and is engineered with silver alloy contacts to minimize contact resistance (100 milliohms), ensuring efficient electrical performance and longevity. It supports switching voltages of up to 1kV DC and 1kV AC, suitable for demanding power relay needs.
Coil resistance stands at 300 ohms with a power consumption of 1.92 watts, contributing to energy efficiency. The contact arrangement is 2 Form A, allowing double-pole single-throw switching operations, commonly needed in electrical control systems.
This relay complies with major international standards such as cULus and VDE, making it reliable for various industrial, electrical, and automation systems including photovoltaic power generation, battery charge/discharge control, and inverter load management.
Compact size and PCB mounting design. High switching current of 20A with silver alloy contacts. Operates reliably from -40°C to 85°C ambient temperatures. Supports switching voltages up to 1kV DC and 1kV AC. Coil powered with 24V DC at 1.92W with 300Ω coil resistance.
Meets cULus and VDE standards for quality and safety. Manufactured in Japan for superior build quality.
This Panasonic power relay is suitable for electrical, automation, automotive, and industrial applications requiring dependable isolation and power switching. Browse our comprehensive category of Power Relays for additional options and contact us for technical support on selecting the right relay.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay has a maximum switching current of 20A.
The coil voltage rating for this model is 24V DC.
The dimensions of the relay are 50mm in length, 41mm in width, and 39.4mm in height.
This relay features a DPST (Double Pole Single Throw) contact configuration with a 2 Form A arrangement.
It operates reliably over a temperature range from -40°C to 85°C.
The contact material is made of high-quality silver alloy, which helps minimize contact resistance.
The coil resistance is rated at 300 ohms.
This relay supports switching voltages of up to 1kV DC and 1kV AC.
It conforms to recognized standards including cULus and VDE for safe industrial use.
The coil power consumption is 1.92 watts.
This relay is designed for PCB mounting.
This relay is manufactured in Japan, ensuring quality and durability.
