| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 0.9mm |
| Length | 2.7mm |
| Model | UDZVTE-173.6B |
| Mount Type | Surface |
| Series | UDZV |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323F |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 10μA |
| Nominal Zener Voltage Vz | 3.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 1000Ω |
ROHM UDZVTE-173.6B is a precision 3.6 V Zener diode designed for voltage regulation in semiconductor applications. It features a single diode configuration inside a surface mount 2-pin SOD-323F package, offering a maximum power dissipation rating of 200 mW. Suitable for industrial and consumer electronics, this diode ensures reliable voltage stabilization under test conditions of 5 mA current.
The device's maximum zener impedance of 1000 ohms enables effective voltage regulation, while its maximum reverse leakage current is just 10 microamperes, ensuring low standby current losses. It is rated for operation at temperatures up to 150°C, making it robust for demanding environments.
With compact dimensions of 2.7 mm length and 0.9 mm height, the diode is suitable for high-density PCB layouts, helping to reduce overall device footprint without sacrificing performance. ROHM's adherence to RoHS environmental standards guarantees the diode is compliant with international manufacturing protocols.
The diode features a single element chip configuration optimized for voltage regulation. Test current rating of 5 mA ensures accurate voltage control. Maximum zener impedance of 1000 ohms improves regulation stability. Rated for maximum power dissipation of 200 mW in compact SOD-323F package.
Operating temperature range supports up to 150°C for industrial use cases. Low maximum reverse leakage current of 10 microamperes to minimize power loss. Compact dimensions enable space-saving surface mount PCB design. RoHS compliant to meet environmental and safety standards.
Ideal for use in electronic circuits requiring precise voltage regulation.
This Zener diode is especially suitable for applications in power management, voltage regulation, and protection circuits within industrial, electronics manufacturing, and research laboratory environments.
Explore more ROHM semiconductor components and related power regulation devices at EnvMart for high reliability and superior quality solutions to your electronic design needs.
Explore more products in our Zener Diodes category.
