XP Power Ultra Miniature Through Hole DC/DC Converter, 300V Output, 1.67 mA, 5V Input, 0.5W Power, Operating Temp Q03-5

XP Power Q03-5 is an ultra miniature through hole DC/DC converter designed to convert low voltage DC input to a high voltage DC output. This compact DC/DC converter delivers a 300V output at 1.67 mA current, powered by a 5V input voltage supply, and supports a maximum output power of 0.5W. The unit operates reliably within temperatures ranging from -25°C to 70°C, making it suitable for various industrial and scientific applications.

The Q Series converter features excellent input/output isolation at 500V, ensuring minimal interference and safe isolation between input and output circuits. Its low ripple and noise specification of 0.25% peak-to-peak ensures stable output suitable for sensitive electronics.

The ultraminiature size and through hole mount type allow easy integration into printed circuit boards, especially in space-limited environments. With a compact footprint of 12.7mm length, width, and depth, it offers a lightweight and robust power solution weighing only 4.3g. The converter boasts an MTBF of 3 million hours, underscoring its high reliability and durability.

Designed without the need for external components, the Q03-5 simplifies system design and lowers overall cost. It includes safeguards such as short circuit protection and low leakage current to enhance operational safety and longevity.

Typical applications for this converter include powering avalanche photodiodes, photomultiplier tubes, piezoelectric devices, sustaining ion pumps, electrophoresis equipment, printers, igniters, and capacitor charging circuits.

The converter features ultra miniature case size for compact designs. Ensures reliable performance with an MTBF of 3,000,000 hours. Provides input/output isolation voltage up to 500V. Low ripple and noise at 0.25% peak-to-peak output.

Short circuit protection enhances safety during fault conditions. Requires no external components, simplifying usage. Operates safely within -25°C to +70°C temperature range. Lightweight construction weighing approximately 4.3 grams.

This DC/DC converter is manufactured in the United States and complies with relevant industry standards, including RoHS and UL guidelines. This Q03-5 DC/DC converter is an excellent choice for industrial, laboratory, medical, and scientific environments where compact size and high voltage outputs are required.
