Bourns Shielded Wirewound Surface Mount Inductor 6.8 μH ±10% 285 mA Idc 27MHz Q:50 CM453232
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 178mm |
| Brand | Bourns |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | CM453232 |
| Depth | 3.2mm |
| Series | CM453232 |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -20°C |
| Core Material | Ferrite |
| Inductance | 6.8μH |
| Standards/Approvals | RoHS |
| Package/Case | 453232 |
| Maximum DC Current | 285mA |
| Pin Count | 2 |
| Maximum DC Resistance | 1200mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 27MHz |
| Minimum Quality Factor | 50 |
| Inductor Construction | Wirewound |
Key Features
- Features a ferrite core for stability and performance.
- Compact package size 453232 with dimensions 4.5 mm length, 3.2 mm height, and 3.2 mm depth.
- Shielded design reduces electromagnetic interference.
- Suitable for surface mount applications with 2 pins termination style.
- Operates reliably in temperature range from -20°C to 100°C.
- Maximum DC resistance of 1200 mΩ ensures efficient current flow.
- Minimum quality factor of 50 and maximum self resonant frequency of 27 MHz.
- Complies with RoHS standards for environmental safety.
Product Description
Bourns CM453232 is a shielded wirewound surface mount inductor designed with a ferrite core offering 6.8 μH inductance and ±10% tolerance. This surface mount device supports a maximum DC current of 285 mA and is engineered for reliable performance in industrial and electronic applications.
The inductor features a compact 453232 package size measuring 4.5 mm in length, 3.2 mm in height, and 3.2 mm in depth suitable for automatic surface mounting. Its shielded construction protects against electromagnetic interference, making it ideal for high-frequency circuits.
With a maximum DC resistance of 1200 mΩ, this inductor ensures efficient operation with minimal loss. It offers a high minimum quality factor of 50 and a maximum self-resonant frequency of 27 MHz, supporting stable signal integrity.
Operating temperature ranges from -20°C to 100°C, allowing usage in demanding environments. The inductor is molded and constructed with wirewound technology and two-pin termination style, enhancing durability and ease of application.
This product conforms to RoHS standards, assuring compliance with environmental regulations. The ferrite core material further contributes to optimized magnetic performance. Features a ferrite core for stability and performance.
Compact package size 453232 with precise dimensions for surface mounting. Shielded design reduces electromagnetic interference in circuits. Suitable for operating temperatures between -20°C and 100°C. Maximum DC current rating of 285 mA ensures reliability.
High minimum quality factor (Q) of 50 enhances electrical efficiency. Maximum self resonant frequency of 27 MHz supports high-frequency applications. Molded wirewound construction provides mechanical robustness. RoHS compliant for environmental safety and regulatory adherence.
This Bourns CM453232 inductor is widely used in electronic manufacturing, power supplies, telecommunications, and industrial electronics for noise filtering, energy storage, and signal conditioning.
Explore more high-quality electronic components and Surface Mount Inductors at EnvMart for versatile industrial and research applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 6.8 μH with a tolerance of ±10%.
The maximum DC current rating for this inductor is 285 mA.
It has a compact package size of 4.5 mm in length, 3.2 mm in height, and 3.2 mm in depth.
The maximum self-resonant frequency is 27 MHz, making it suitable for high-frequency applications.
It operates reliably within a temperature range of -20°C to 100°C.
This inductor features a two-pin surface mount termination style.
The maximum DC resistance is 1200 mΩ, ensuring efficient current flow.
It is constructed with a ferrite core, which contributes to its stability and performance.
Yes, this inductor complies with RoHS standards for environmental safety.
The minimum quality factor (Q) is 50, enhancing its electrical efficiency.
This inductor is widely used in electronic manufacturing, power supplies, telecommunications, and industrial electronics for noise filtering and signal conditioning.
It features a wirewound construction, which provides mechanical robustness and performance stability.
