XP Power Switching Power Supply 1.5 kW 48V DC Chassis Mount 264V AC HPU1K5PS48-M

Free Delivery in India | Lowest Global Shipping Charges

XP Power Switching Power Supply 1.5 kW 48V DC Chassis Mount 264V AC HPU1K5PS48-M

Name: XP Power Switching Power Supply 1.5 kW 48V DC Chassis Mount 264V AC HPU1K5PS48-M
Brand: XP Power
SKU: 140702



Category Power Supplies & Transformers Brand XP Power Condition New

Specifications

Country of Origin	China
Brand	XP Power
Power	1.5kW
Efficiency	90%
Length	323.9mm
Model	HPU1K5PS48-M
Depth	43.2mm
Gross Weight	1.3kg
Width	101.6mm
Mount Type	Chassis
Series	HPU
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-20°C
Number of outputs	1
Maximum Input Voltage	264V ac
Maximum Output Voltage	48V dc
SMPS Output Current	31A
Minimum Input Voltage	85V ac

Key Features

Provides 1.5 kW maximum output power with 48V DC voltage.
Operates efficiently at 90% efficiency to reduce power loss.
Single output design delivering 31A current for stable supply.
Wide operating temperature range from -20°C to 70°C for reliability.
Equipped with a variable fan speed to minimize audible noise during operation.
Designed to mount on chassis with compact dimensions (323.9mm x 101.6mm x 43.2mm).
Meets multiple safety and medical standards including CSA-22.2 No.60601-1, UL60950, EN60601-1.
Supports input voltage from 85V to 264V AC for versatility.

Product Description

XP Power HPU1K5PS48-M is a high-performance switching power supply designed for industrial and medical applications requiring reliable 48V DC power output. Rated at 1.5 kW with chassis mount design, it supports a wide input voltage range of 85V to 264V AC, accommodating diverse power environments.

This power supply operates at 90% efficiency ensuring minimal energy waste and heat generation. It features a variable fan speed mechanism that reduces operational noise significantly, promoting quieter working conditions. The unit supports a single output delivery of 31A current, suitable for stable, heavy-load applications.

Engineered for demanding conditions, it operates reliably from -20°C to +70°C, making it applicable in harsh industrial settings. The compact dimensions of 323.9mm length, 101.6mm width, and 43.2mm depth enable easy integration into chassis mounting installations.

Comprehensive safety standards compliance includes CSA-22.2 No.60601-1 certified per cUL, EN 60601-1, UL 60950, and ANSI/AAMI ES 60601-1, ensuring safety and regulatory adherence especially in medical environments.

It incorporates advanced features such as AC OK and DC OK signals, inhibit function, fan failure monitoring, and high-temperature alerts, enhancing operational safety and maintenance diagnostics.

Ideal for use in industrial machines, medical devices, laboratory equipment, manufacturing plants, and HVAC systems, this switching power supply ensures dependable power conversion with robust protection mechanisms.

The product is manufactured in China, reflecting high-quality production standards by XP Power, a reputable name in power supply solutions. Provides 1.5 kW maximum output power with 48V DC voltage. Operates efficiently at 90% efficiency to reduce power loss.

Single output design delivering 31A current for stable supply. Wide operating temperature range from -20°C to 70°C for reliability. Equipped with a variable fan speed to minimize audible noise during operation. Designed to mount on chassis with compact dimensions (323.9mm x 101.6mm x 43.2mm).

Meets multiple safety and medical standards including CSA-22.2 No.60601-1, UL60950, EN60601-1. Supports input voltage from 85V to 264V AC for versatility. Includes protective features such as AC OK, DC OK, inhibit, and 5 V standby signals.
