| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 6.5mm |
| Length | 7.2mm |
| Model | R82EC2680DQ60J |
| Packaging | Ammo Pack |
| Width | 2.5mm |
| Mount Type | Through Hole |
| Series | R82 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 68nF |
| Minimum Operating Temperature | -55°C |
| Lead Length | 18.5mm |
| Standards/Approvals | IEC 60384-2, RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 63V ac |
| Rated DC Voltage | 100V dc |
| Lead Pitch | 5mm |
| Lead Diameter | 0.5mm |
| Automotive Standard | AEC-Q100 |
| Panasonic ECQV(L) Polyester Film Capacitor, 50V dc, ±5%, 68nF, Through HoleBrand | Panasonic |
| Panasonic ECQV(M) Polyester Film Capacitor, 63V dc, ±5%, 56nF, Through HoleBrand | Panasonic M |
KEMET R82EC2680DQ60J film capacitor is a metallised polyester film capacitor with a capacitance of 68 nF and a tolerance of ±5%. It is rated for 100 V DC and 63 V AC, designed for through hole mounting with a 5 mm lead pitch. This capacitor features radial leads made of tinned wire, electrically welded to the metal layer of the capacitor winding. The device is encapsulated in a self-extinguishing, solvent-resistant plastic case using thermosetting resin, making it robust for varied industrial environments.
Its operating temperature range of -55°C to +105°C supports demanding industrial, automotive, and electronic circuit applications such as oscillators, timing circuits, coupling, blocking, and decoupling. The capacitor complies with IEC 60384-2 and RoHS directives ensuring electrical safety and eco-friendly compliance, while also meeting automotive AEC-Q100 standards for quality in automotive electronics.
The R82EC2680DQ60J offers a lead diameter of 0.5 mm, a lead length of 18.5 mm, and a small form factor measuring 7.2 mm in length, 6.5 mm in height, and 2.5 mm in width, facilitating compact PCB layouts. Its ammo pack packaging enhances convenient storage and handling in production environments.
Typical use cases include use in industrial electronic assemblies, laboratory equipment, automotive systems, and telecommunications where stable high-frequency and pulse applications are critical.
Metallised polyester film capacitor construction. Radial leads with 5 mm pitch facilitate mounting. Wide operating temperature from -55°C to +105°C. Compliant with IEC 60384-2, RoHS, and automotive AEC-Q100 standards. Ideal for oscillator, timing, decoupling, coupling, and blocking applications.
Compact dimensions support integration in space-constrained circuitry. Self-extinguishing encapsulation ensures safe operation. Ammo pack packaging for ease of handling in manufacturing. Explore the full range of Film Capacitors and other electronic components on EnvMart to source quality parts for your industrial and commercial projects.
