MEAN WELL LRS-35-15 36W 15V DC Switching Power Supply Chassis Mount LRS-35-15

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL LRS-35-15 36W 15V DC Switching Power Supply Chassis Mount LRS-35-15

Name: MEAN WELL LRS-35-15 36W 15V DC Switching Power Supply Chassis Mount LRS-35-15
Brand: MEAN WELL
SKU: 138625
Price: 20.22 USD
Availability: InStock



Category Switching Power Supply Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Power	36W
Efficiency	86%
Length	99mm
Model	LRS-35-15
Depth	30mm
Gross Weight	230g
Width	82mm
Mount Type	Chassis
Series	LRS-35
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	373, 264V dc
Maximum Output Voltage	15V dc
SMPS Output Current	2.4A
Minimum Input Voltage	85V ac

Key Features

Provides a single 15V DC output with a maximum current of 2.4A.
Robust chassis mount type casing for secure installation.
Wide operating temperature range from -30°C to 70°C for diverse environments.
High efficiency of approximately 86% with low no-load power consumption below 0.2W.
Supports universal AC input voltage from 85V AC up to 373V DC for flexible power sources.
Includes 5G vibration resistance and free air convection cooling for reliable operation.
Complies with international standards such as UL 62368-1, TUV EN 62368-1, CSA C22.2 and others.
Compact dimensions of 99mm (L) x 82mm (W) x 30mm (D) and lightweight at 230 grams.

Product Description

MEAN WELL LRS-35-15 switching power supply is a highly efficient 36W single-output power unit delivering a stable 15V DC output at 2.4A. The power supply features a robust chassis mount design with compact dimensions of 99mm length, 82mm width, and 30mm depth, making it suitable for installation in various electrical and mechanical equipment.

This model operates reliably within a wide ambient temperature range of -30°C to 70°C and withstands 5G vibration, ensuring durability in demanding industrial environments. The universal AC input supports voltages from 85V AC up to 373V DC and includes a 300V surge capability for 5 seconds.

With an efficiency rating of approximately 86% and extremely low no-load power consumption below 0.2W, the LRS-35-15 is energy efficient and environmentally friendly. Cooling is achieved through free air convection, eliminating the need for additional fans and enhancing reliability.

The power supply carries certifications to multiple international safety standards including UL 62368-1, TUV EN 62368-1, CSA C22.2, and GB4943.1 ensuring it meets global compliance requirements. This unit is designed for applications in industrial automation, control machinery, electrical equipment, and household appliances requiring dependable power conversion.

Provides a single 15V DC output with a maximum current of 2.4A. Robust chassis mount type casing for secure installation. Wide operating temperature range from -30°C to 70°C for diverse environments. High efficiency of approximately 86% with low no-load power consumption below 0.2W.

Supports universal AC input voltage from 85V AC up to 373V DC for flexible power sources. Includes 5G vibration resistance and free air convection cooling for reliable operation. Complies with international standards such as UL 62368-1, TUV EN 62368-1, CSA C22.2 and others.

Compact dimensions of 99mm (L) x 82mm (W) x 30mm (D) and lightweight at 230 grams. Designed primarily for industrial automation, machinery, and household appliances. Explore the MEAN WELL Switching Power Supply range at EnvMart for reliable industrial and commercial power solutions.
