MEAN WELL EPS-65S-24 Switching Power Supply 24V DC 65W 2.71A Chassis Mount EPS-65S
Specifications
| Country of Origin | India |
|---|---|
| Brand | MEAN WELL |
| Power | 65W |
| Efficiency | 88% |
| Length | 101.6mm |
| Model | EPS-65S-24 |
| Depth | 29mm |
| Gross Weight | 150g |
| Width | 29mm |
| Mount Type | Chassis |
| Series | EPS-65S |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -30°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 370, 264V dc |
| Standards/Approvals | EAC TP TC 004, IEC 6681, UL 6681, TUV BS ENEN 6681 |
| Maximum Output Voltage | 24V dc |
| SMPS Output Current | 2.71A |
| Minimum Input Voltage | 90V ac |
Key Features
- Designed for chassis mounting with compact dimensions and a miniature 3 x 2 inch size.
- Accepts wide input voltage range from 90V AC to 264V AC with a maximum DC input voltage of 370V.
- Provides reliable operation from -30°C to 70°C ambient temperature.
- Includes short circuit, overload and over voltage protections with EMI Class B rating.
- Features convection cooling and LED power status indication for enhanced reliability.
- Complies with international standards including EAC TP TC 004, IEC 6681, UL 6681, and TUV BS ENEN 6681.
- Suitable for industrial automation machinery, electrical equipment, and industrial control systems.
Product Description
MEAN WELL EPS-65S-24 is a compact Switching Power Supply designed to provide a stable 24V DC output at 65W power with 2.71A output current. The unit supports chassis mounting and features a miniature form factor suitable for 1U applications.
This power supply accepts a wide AC input voltage range from 90V to 264V AC and supports a maximum DC input voltage of 370V. It operates reliably at ambient temperatures ranging from -30°C to 70°C, ensuring performance in demanding industrial environments.
The EPS-65S-24 includes important electrical protections such as short circuit, overload, and over voltage safeguards to enhance operational safety and longevity. It meets EMI Class B standards and uses free air convection cooling for silent operation. An LED indicator provides clear visual feedback of power status.
Compliance to standards including EAC TP TC 004, IEC 6681, UL 6681, and TUV BS ENEN 6681 ensures safety and reliability in various industrial and commercial applications.
Common use cases for this power supply unit include industrial automation machinery, mechanical and electrical equipment, industrial control systems, and electronic instruments or apparatus.
Its compact size and wide operating conditions make it ideal for integration into control cabinets, panel assemblies, and embedded power supply solutions. Designed for chassis mounting with compact dimensions and a miniature 3 x 2 inch size.
Accepts wide input voltage range from 90V AC to 264V AC with a maximum DC input voltage of 370V. Provides reliable operation from -30°C to 70°C ambient temperature. Includes short circuit, overload and over voltage protections with EMI Class B rating.
Features convection cooling and LED power status indication for enhanced reliability. Discover a wide selection of switching power supplies in the Electronics & Electricals category at EnvMart designed for industrial and commercial power management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The EPS-65S-24 provides a stable output voltage of 24V DC with a maximum output current of 2.71A.
It accepts a wide input voltage range from 90V AC to 264V AC and supports a maximum DC input voltage of 370V.
The unit has compact dimensions of 101.6mm in length, 29mm in width, and 29mm in depth.
It operates reliably in ambient temperatures ranging from -30°C to 70°C.
This power supply includes short circuit, overload, and over voltage protections to enhance operational safety.
The power supply has an efficiency rating of 88%.
It features convection cooling for silent operation.
The EPS-65S-24 is designed for chassis mounting.
It complies with EAC TP TC 004, IEC 6681, UL 6681, and TUV BS ENEN 6681 standards.
The gross weight of this model is 150g.
It is suitable for industrial automation machinery, electrical equipment, and industrial control systems.
This power supply has one output.
