KEMET R60 Film Capacitor ±5% 100nF 630V DC 220V AC Through Hole R60PI3100AA30J
Specifications
| Country of Origin | India |
|---|---|
| Capacitance Range | 0.001 μF - 150.0 μF |
| Voltage Range | 50 to 1000 V dc |
| Brand | KEMET |
| Height | 13.5mm |
| Length | 18mm |
| Model | R60PI3100AA30J |
| Packaging | Bag |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | R60 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 100nF |
| Minimum Operating Temperature | -55°C |
| Climatic category | 55/105/56 |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, UL 94V-0, RoHS |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 220V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 10.0 to 37.5 mm |
Key Features
- Offers stable capacitance value of 100 nanofarads with tight ±5% tolerance.
- Designed for use in coupling, timing, blocking, bypassing, and oscillator circuits.
- Rated for a DC voltage up to 630 volts and AC voltage of 220 volts.
- Constructed with a plastic case and radial leads suitable for through-hole mounting.
- Operates safely across a temperature range of -55°C to 105°C.
- Lead pitch measures 15mm with 0.8mm lead diameter and 25mm lead length.
- Complies with IEC 60286-2, UL 94V-0 flammability standards, and RoHS directive.
- Features self-extinguishing, solvent-resistant plastic encapsulation with thermosetting resin.
Product Description
KEMET R60PI3100AA30J is part of the R60 Series polyester film capacitors featuring a capacitance of 100nF with a ±5% tolerance, rated for 630V DC and 220V AC voltage. This capacitor utilizes radial tinned wire leads and is intended for through-hole mounting applications.
The capacitor's film winding is electrically welded to contact metal layers at the ends, and it is encased in a thermosetting resin plastic case that is solvent-resistant and self-extinguishing to meet UL 94V-0 standards. Operating temperature ranges from -55°C to 105°C, making it suitable for harsh industrial and automotive environments.
It has a lead pitch of 15mm and lead length of 25mm with a lead diameter of 0.8mm. Compliance with IEC 60286-2 and RoHS ensures safety and environmental considerations. The capacitor is suitable for applications such as coupling, timing, blocking, bypassing, oscillators, and interference suppression in low voltage electronic systems.
Automotive qualified versions compliant with AEC-Q200 standard are available for applications requiring stringent automotive quality and reliability standards, especially for lead pitches up to 22.5mm.
Stable capacitance with ±5% tolerance ensures circuit reliability. High voltage ratings for DC and AC applications enhance versatility. Plastic encapsulation and UL 94V-0 rated resin provide superior safety. Wide operating temperature supports diverse industrial and automotive conditions.
Lead pitch and length are suited for standard through-hole assembly. RoHS compliance aligns with environmental regulations. Automotive grade availability extends usage into mobility solutions. Applications include filtering, bypassing, coupling, blocking, and oscillators.
Explore KEMET Film Capacitors and other electronics components at EnvMart for your industrial, automotive, and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 100nF with a tolerance of ±5%.
It is rated for a DC voltage of 630V and an AC voltage of 220V.
This unit operates safely across a temperature range of -55°C to 105°C.
The dimensions are 18mm in length, 7.5mm in width, and 13.5mm in height.
It features a lead pitch of 15mm, a lead diameter of 0.8mm, and a lead length of 25mm.
It complies with IEC 60286-2, UL 94V-0 standards, and is RoHS compliant.
This model is designed for through-hole mounting applications.
It is suitable for applications such as coupling, timing, blocking, bypassing, and oscillator circuits.
It is constructed with a plastic case and features radial leads.
Yes, automotive qualified versions compliant with AEC-Q200 standards are available.
The capacitor is packaged in a bag.
The climatic category for this model is 55/105/56.
