Microchip Operational Amplifier, Gain Bandwidth 550 kHz, 5-Pin SOT-23, 2.2V - 10V Supply, 0.5V/μs Slew Rate MIC7300YM5-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.3mm |
| Length | 3.02mm |
| Model | MIC7300YM5-TR |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | MIC7300 |
| Output Current | 40mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Maximum Supply Voltage | 10V |
| Minimum Supply Voltage | 2.2V |
| GBP - Gain Bandwidth Product | 550kHz |
| Input Bias Current | 0.5 pA |
| Vos - Input Offset Voltage | 9 mV |
| Slew Rate | 0.5V/μs |
| Input Offset Current | 0.25 pA |
| MIC7300YM5 TR Micrel, Op Amp, 400kHz, 3 → 9 V, 5-Pin SOT-23Brand | Micrel |
Key Features
- Single-channel operational amplifier designed for surface mounting.
- Gain bandwidth product of 550 kHz provides versatile frequency response.
- Low input bias current of 0.5 pA ensures high accuracy.
- Slew rate of 0.5 V/μs supports moderate speed signal processing.
- Compact SOT-23 package with 5 pins ideal for space-constrained applications.
- Operating temperature range from -40°C to 85°C suits industrial environments.
- Typical input offset voltage of 9 mV helps maintain signal integrity.
- Maximum output current rating of 40 mA for robust load driving.
Product Description
Microchip MIC7300YM5-TR is a high-performance operational amplifier designed for electronic and semiconductor applications requiring precision in signal amplification.
This device operates with a supply voltage range from 2.2V up to 10V and delivers a gain bandwidth product of 550 kHz, allowing for efficient signal processing in various industrial, laboratory, and consumer electronics applications.
The compact 5-pin SOT-23 package makes it suitable for surface mounting on printed circuit boards where space constraints are critical. Its low input bias and offset currents ensure minimal signal distortion, contributing to accurate and stable operation.
With a slew rate of 0.5 V/μs and maximum output current of 40 mA, it handles moderate frequency signal amplification tasks efficiently. The operational temperature range from -40°C to 85°C makes it reliable for harsh industrial environments and automotive-level conditions, although it does not conform to automotive standards.
This operational amplifier complies with RoHS directives, aligning with modern environmental and manufacturing standards. Single-channel precision operational amplifier suitable for surface mount technology. Gain bandwidth product of 550 kHz ensures practical frequency response.
Low input bias current minimizes measurement error. Compact SOT-23 5-pin package supports high-density layouts. Wide operating temperature range for robust industrial applications. Low input offset voltage and current enhance signal fidelity.
Maximum output current of 40 mA supports a variety of load conditions. RoHS compliant for sustainable manufacturing. Ideal for use in electronic, semiconductor, instrumentation, and control applications. Package dimensions: length 3.02 mm, width 1.75 mm, height 1.3 mm.
Choose Microchip Operational Amplifiers for precision amplification needs in electronics, semiconductor manufacturing, instrumentation, and communications. Explore the full Microchip product range and download technical documents and 3D models available for your design projects at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the MIC7300YM5-TR operational amplifier is 550 kHz, allowing for efficient signal processing across various applications.
This operational amplifier operates with a supply voltage range from 2.2V to 10V, making it versatile for different electronic applications.
The maximum output current rating for this model is 40 mA, which supports various load conditions during operation.
It has an operating temperature range from -40°C to 85°C, suitable for industrial environments and applications.
The input bias current for the MIC7300YM5-TR is 0.5 pA, which helps ensure high accuracy in signal amplification.
The slew rate of this operational amplifier is 0.5 V/μs, supporting moderate speed signal processing tasks.
The SOT-23 package dimensions are 3.02 mm in length, 1.75 mm in width, and 1.3 mm in height, making it compact for space-constrained applications.
This model is a single-channel operational amplifier, designed for precise signal amplification.
The typical input offset voltage for the MIC7300YM5-TR is 9 mV, which helps maintain signal integrity during operation.
This operational amplifier is designed for surface mounting, making it suitable for high-density layouts on printed circuit boards.
Yes, the MIC7300YM5-TR complies with RoHS directives, aligning with modern environmental and manufacturing standards.
This operational amplifier is suitable for use in electronic, semiconductor, instrumentation, and control applications.
