Wurth Elektronik WR-PHD Series 2.54mm Pitch Right Angle Through Hole Pin Header, 32 Contacts, 2 Rows, Unshrouded 61303221021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 32 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- The connector features 2 rows of unshrouded male pins with a 2.54 mm pitch.
- Constructed with a polyamide housing ensuring durability and insulation.
- Gold plated copper alloy contacts provide reliable electrical connection and corrosion resistance.
- Rated for a current of 3A and voltage of 250V suitable for PCB board-to-board connections.
- Designed with right angle orientation and through hole mount type for stable PCB mounting.
- Operating temperature range from -40°C to 105°C for extended environmental resilience.
- Tail pins are 3mm long with mating pin length of 6mm for secure solder joint and connector engagement.
Product Description
Wurth Elektronik 61303221021 WR-PHD Series right angle through hole pin header connectors feature a precise 2.54 mm pitch and 32 male contacts arranged in 2 rows. This unshrouded connector is designed for high-reliability board-to-board mounting applications requiring a robust electrical connection.
The pins are made from copper alloy with gold plating to prevent corrosion and ensure long-term conductivity. The polyamide (UL94-V0 rated) housing provides excellent insulation and mechanical support. Rated for a maximum current of 3A and voltage of 250V, it supports demanding electronic designs.
Engineered for through hole mounting, the right angle orientation allows compact PCB layouts while maintaining strong mechanical stability and ease of soldering. The connector operates reliably across a temperature range of -40°C to 105°C, ideal for harsh industrial and commercial environments.
Its features include 3mm tail pin length and 6mm mating pin length to guarantee secure solder joints and connector mating. The WR-PHD series by Wurth Elektronik is a trusted solution for electronic component interconnections in industrial, telecommunications, instrumentation, and manufacturing sectors.
This product is made in Taiwan, Province Of China, affirming its quality and international standards compliance. The connector features 2 rows of unshrouded male pins with a 2.54 mm pitch. Constructed with a polyamide housing ensuring durability and insulation.
Gold plated copper alloy contacts provide reliable electrical connection and corrosion resistance. Rated for a current of 3A and voltage of 250V suitable for PCB board-to-board connections. Designed with right angle orientation and through hole mount type for stable PCB mounting.
Operating temperature range from -40°C to 105°C for extended environmental resilience. Tail pins are 3mm long with mating pin length of 6mm for secure solder joint and connector engagement. Explore the range of Wurth Elektronik PCB headers and Connectors on EnvMart for reliable electronics manufacturing and design integration.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header features a pitch size of 2.54 mm.
This model has 32 male contacts arranged in 2 rows.
It is rated for a maximum current of 3A and a voltage of 250V.
The operating temperature range is from -40°C to 105°C.
The housing is constructed from polyamide, which provides insulation and mechanical support.
This connector is designed for through hole mounting.
The tail pins are 3 mm long.
The mating pins have a length of 6 mm.
This connector is unshrouded, allowing for easier access during mating.
The termination type for this connector is solder.
This pin header is suitable for board-to-board connections in various electronic applications.
This product is manufactured in Taiwan, Province Of China.
