Wurth Elektronik WR-PHD Series 2.54mm Pitch Right Angle Through Hole Pin Header Connector 14 Contacts 2 Row 61301421021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- The connector features a right angle orientation for flexible PCB mounting.
- It has 14 male contacts spread over 2 rows with 2.54mm pitch.
- Contacts are made from gold-plated copper alloy ensuring reliable signal integrity.
- The housing is constructed from black polyamide with UL94-V0 flammability rating.
- Suitable for operation between -40°C and 105°C temperatures.
- Termination is solder type suitable for through-hole mounting.
- Rated for a maximum voltage of 250V and current rating of 3A.
- Tail pin length is 3mm and mating pin length is 6mm for secure connections.
Product Description
Wurth Elektronik 61301421021 WR-PHD Series is a high-quality right angle through hole pin header connector designed for board-to-board connections in electronic assemblies. It features dual rows with 14 unshrouded contacts spaced at 2.54mm pitch, ideal for compact and reliable PCB interconnections.
The contacts are manufactured from copper alloy with gold plating to ensure excellent conductivity and corrosion resistance. The black polyamide housing complies with UL94-V0 flame retardant standards, providing safety and durability in various industrial and commercial applications.
This connector operates reliably in a broad temperature range from -40°C to 105°C and supports electrical ratings of up to 250 volts and 3 amperes of current, making it suitable for a wide range of electronic equipment including power supplies, control systems, instrumentation, and automation devices.
Assembly is simplified with its through hole mount type and solder termination, while the right angle orientation helps save PCB space and enables convenient routing. Tail pins of 3mm and mating pins of 6mm length facilitate robust mating and mechanical integrity.
The connector features a right angle orientation for flexible PCB mounting. It has 14 male contacts spread over 2 rows with 2.54mm pitch. Contacts are made from gold-plated copper alloy ensuring reliable signal integrity.
The housing is constructed from black polyamide with UL94-V0 flammability rating. Suitable for operation between -40°C and 105°C temperatures. Termination is solder type suitable for through-hole mounting. Rated for a maximum voltage of 250V and current rating of 3A.
Tail pin length is 3mm and mating pin length is 6mm for secure connections.
This Wurth Elektronik WR-PHD Series connector is widely used in industrial electronic, laboratory instrumentation, HVAC controls, telecommunications, and manufacturing equipment where reliable board-to-board connections are critical. It is engineered to meet demanding electrical and mechanical requirements with proven durability.
Explore more high-performance PCB headers and Connectors at EnvMart for your electronics design and assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a maximum voltage of 250V.
The current rating for this model is 3A.
The contacts are spaced at a pitch of 2.54mm.
This connector features 14 male contacts spread over 2 rows.
The contacts are made from gold-plated copper alloy, and the housing is constructed from black polyamide.
It operates reliably between -40°C and 105°C.
The termination type is solder, suitable for through-hole mounting.
This connector features a right angle orientation, which allows for flexible PCB mounting.
The tail pin length is 3mm and the mating pin length is 6mm.
This model is unshrouded, providing easier access for mating.
It is suitable for use in industrial electronics, laboratory instrumentation, HVAC controls, telecommunications, and manufacturing equipment.
The country of origin for this connector is Taiwan.
