Bourns Shielded Wirewound Surface Mount Inductor SRN5040 with Ferrite Core 6.8 μH ±20% 2.3 A Idc Q15 SRN5040
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 4mm |
| Length | 5mm |
| Model | SRN5040 |
| Depth | 5mm |
| Packaging | Reel |
| Series | SRN5040 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 1.5 to 47 μH |
| Inductance | 6.8μH |
| Standards/Approvals | RoHS |
| Package/Case | 5040 |
| Maximum DC Current | 2.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 59mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 21MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Wirewound |
Key Features
- The device features a ferrite core and wirewound construction for enhanced performance.
- It has a semi-shielded 5040 package case, suitable for high-density PCB layouts.
- Operating temperature range is from -40°C to 125°C for reliable use in diverse environments.
- Maximum DC resistance is 59 milliohms ensuring low power loss in circuits.
- The inductor has a maximum self-resonant frequency of 21 MHz and a quality factor of at least 15.
- It uses solder termination style suitable for automated assembly.
- Compliant with RoHS standards and molded for robustness.
- Applications include DC/DC converters, notebooks, digital video cameras, HDDs, cellphones, TVs, and LCD displays.
Product Description
Bourns SRN5040 Shielded Wirewound Surface Mount Inductor is a high-performance inductor featuring a ferrite core with wirewound construction offering 6.8 μH inductance at ±20% tolerance. Designed for surface mount technology, it comes in a compact 5040 semi-shielded package suitable for various industrial and consumer electronic applications.
This inductor supports a maximum DC current rating of 2.3 A and withstands operating temperatures ranging from -40°C up to 125°C, making it ideal for demanding environments. The maximum DC resistance is 59 milliohms, minimizing power loss and improving energy efficiency within circuits.
Its maximum self-resonant frequency is 21 MHz, ensuring stable behavior in high-frequency switching power supplies and DC/DC converter circuits. The minimum quality factor of 15 enhances its filtering performance. The device features solder termination style allowing easy PCB mounting and is molded for durability.
Bourns SRN5040 is RoHS compliant, ensuring environmental safety and compatibility with global electronics manufacturing standards.
Typical applications include DC/DC converters, notebook computers, digital video cameras, hard disk drives (HDDs), cell phones, televisions, and LCD display devices where space saving and performance reliability are critical.
The device features a ferrite core and wirewound construction for enhanced performance. It has a semi-shielded 5040 package case, suitable for high-density PCB layouts. Operating temperature range is from -40°C to 125°C for reliable use in diverse environments.
Maximum DC resistance is 59 milliohms ensuring low power loss in circuits. The inductor has a maximum self-resonant frequency of 21 MHz and a quality factor of at least 15. It uses solder termination style suitable for automated assembly.
Compliant with RoHS standards and molded for robustness. Applications include DC/DC converters, notebooks, digital video cameras, HDDs, cellphones, TVs, and LCD displays.
Explore EnvMart for a broad range of electronic components including Surface Mount Inductors from Bourns and other leading manufacturers to meet your industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRN5040 inductor has an inductance value of 6.8 μH with a tolerance of ±20%.
This model supports a maximum DC current rating of 2.3 A.
The dimensions of the SRN5040 are 5 mm in length, 5 mm in depth, and 4 mm in height.
The maximum operating temperature for the SRN5040 is 125°C.
The maximum self-resonant frequency of this inductor is 21 MHz.
It uses a solder termination style suitable for automated assembly.
The core material of the SRN5040 is ferrite.
The maximum DC resistance is 59 milliohms.
The minimum quality factor for this model is 15.
The SRN5040 inductor is packaged in a reel format.
Yes, the SRN5040 is compliant with RoHS standards.
