Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±20 % 3.24 A IDC DR125-470-R

Eaton DR125-470-R shielded wirewound Surface Mount Inductor incorporates a ferrite core construction, providing a reliable inductance of 47 μH with a tolerance of ±20%. Designed to operate at a maximum DC current of 3.24 A and withstand temperatures up to 125°C, this inductor features a surface mount termination style that facilitates compact PCB layouts.

The inductor's construction using wirewound technology ensures high power density and efficiency, while the magnetic shielding reduces electromagnetic interference. Its maximum DC resistance is 74 mΩ, optimizing performance by limiting energy loss during electrical conduction.

Suitable for diverse applications such as computers, DVD players, LCD panels, and various DC-DC converters including buck, boost, forward, and resonant converters, this component excels in noise filtering and serves as an effective filter choke. The design complies with RoHS standards, confirming its environmentally safe manufacture.

Physical dimensions include a case size of 0125, height of 6mm, and depth of 12.5mm, packaged conveniently on a reel for efficient automated assembly processes. This component originates from China and forms part of Eaton's DR series magnetically shielded wirewound inductors.

Ferrite core enhances magnetic shielding and performance. Wirewound construction delivers high power density and efficiency. 125°C maximum operating temperature for durable operation. Surface mount termination for ease of PCB integration.

Ideal for DC-DC converters and noise filtering applications. Low DC resistance reduces power loss. RoHS compliant to meet environmental standards. Compact 0125 package on reel suitable for automated assembly.
