Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±20 % 7.17A Maximum DC Current DR125-100-R

Eaton DR125-100-R is a shielded wirewound Surface Mount Inductor featuring a ferrite core, delivering 10 μH inductance with ±20 % tolerance and supporting a maximum DC current of 7.17 A. This inductor is designed for use in demanding industrial and electronic applications requiring compact, efficient power storage and filtering.

The inductor utilizes a magnetically shielded wirewound construction to reduce electromagnetic interference, which is essential for maintaining signal integrity in electronic circuits. The ferrite core provides high efficiency and reduced core losses, promoting stable performance in power management systems.

This surface mount component is housed in a 0125 package case with precise dimensions: 12.5 mm in length, 6 mm in height, and 12.5 mm in depth, facilitating easy integration into modern PCB layouts. It features a maximum DC resistance of only 18.9 mΩ, minimizing energy losses.

Operating temperature range spans from -40°C up to 125°C, supporting reliability in automotive, industrial, and consumer electronic applications. Eaton DR series inductors are widely used in computers, DVD players, portable devices, LCD panels, DC-DC converters including buck, boost, forward and resonant converters, noise filtering, and filter choke circuits.

Wirewound construction with ferrite core for efficient energy storage and magnetic performance. Shielded for electromagnetic interference reduction, improving circuit stability. Surface mount termination style compatible with automated PCB assembly.

Wide operating temperature range from -40°C to 125°C ensures durability. RoHS compliant, moulded construction for reliable mechanical strength and environmental safety. Maximum DC current rating of 7.17 A supports medium power applications.

Package dimensions optimized for compact layouts, aiding in space-saving designs. Maximum self-resonant frequency of 100 kHz for stable operation in switching circuits.

This component is manufactured in China and is part of Eaton's DR series of magnetically shielded wirewound chokes known for their high power density and efficiency. Suitable for use in industrial electronics, telecommunications, computing, and other commercial electronic devices. Explore our wide range of inductors at EnvMart for advanced electronic component solutions.
