Samtec TSM Series Right Angle Surface Pin Header, 12 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-112-01-L-SH
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 7A |
| Model | TSM-112-01-L-SH |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 5.84mm |
Key Features
- Constructed with a liquid crystal polymer housing for high durability.
- Phosphor bronze contacts plated with 0.25μm gold ensure reliable conductivity.
- Designed for surface mount technology board-to-board and wire-to-board connections.
- Supports a current rating of 7A and voltage up to 475V.
- Operates within a temperature range of -55°C to 125°C for diverse environments.
- Unshrouded male contacts with a mating pin length of 5.84 mm.
- Right angle orientation allows for compact PCB assembly layouts.
- Termination type is solder ensuring secure and stable connections.
Product Description
Samtec TSM-112-01-L-SH is a right angle surface pin header designed for SMT applications requiring board-to-board and wire-to-board connections. Featuring a 2.54 mm pitch and 12 male contacts arranged in a single row, this connector is built with a durable liquid crystal polymer housing for long-lasting performance in industrial and commercial electronics.
The phosphor bronze contacts plated with a thin layer of gold (0.25μm) deliver excellent electrical conductivity and corrosion resistance. This header supports a current of up to 7 amperes and a voltage rating of 475 volts, making it suitable for a variety of moderate power electronic circuits.
With an operating temperature range from -55°C to 125°C, it can withstand harsh environmental conditions often encountered in industrial, automation, and communication equipment. The mating pin length of 5.84 mm and unshrouded design allow for reliable solder termination and easy mating with compatible connectors.
Its right angle orientation is well suited for space-constrained PCB layouts, ensuring efficient use of board real estate. The surface mount termination type facilitates automated PCB assembly processes, enhancing production consistency and reliability.
These Samtec TSM series headers are commonly used in electronics manufacturing, laboratory instrumentation, communication devices, and automotive electronics, among other professional sectors.
Constructed with a liquid crystal polymer housing for high durability. Phosphor bronze contacts plated with 0.25μm gold ensure reliable conductivity. Supports 7A current and 475V voltage for moderate power applications. Operates in temperatures ranging from -55°C to 125°C.
Right angle, single row, 12 contacts with 2.54 mm pitch. Unshrouded male contacts facilitate secure solder connections. Fits industrial, laboratory, manufacturing, and electronics assembly uses. Explore the Electronics Components category on EnvMart for a wide selection of PCBs, connectors, and related components that meet industrial quality and performance standards.
Explore more products in our PCB Headers category.
