Schneider Electric LC1D50AN7 Contactor, 400V AC Coil, 3-Pole, 50A, 33 kW 415V, 3 NO, 690V AC/DC LC1D50AN7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 122mm |
| Model | LC1D50AN7 |
| Depth | 120mm |
| Width | 55mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Power Rating | 33kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, CSA |
| Contact Voltage | 690V ac/dc |
| Coil Voltage | 400V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 50A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 50A |
| Control Circuit Voltage Uc | 415V |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- This contactor supports a contact current of 50A and power rating of 33 kW at 415V.
- Equipped with 3 normally open (NO) poles and 2 auxiliary contacts configured as 1 NO and 1 NC.
- Mountable on DIN rails with screw clamp terminals for load and auxiliary connections.
- Operates reliably in temperatures ranging from -5°C to 60°C.
- Certified to multiple standards including UL, CSA, IEC, CCC, EAC, and Marine.
- Designed for high operating rates of up to 3600 cycles per hour.
- Eco-friendly Green Premium product compliant with RoHS and REACh directives.
Product Description
Schneider Electric LC1D50AN7 contactor is a robust and reliable device specifically engineered for motor control and resistive load applications. Featuring a 400V AC coil and a 3-pole design, it is capable of handling currents up to 50A and offers a power rating of 33 kW at 415V. This contactor is part of the LC1D series, which is widely used in industrial, commercial, and HVAC systems for efficient motor switching and control.
The product includes three normally open main contacts and two auxiliary contacts with 1 NO and 1 NC configuration, where the normally closed auxiliary contact is mirror certified. It utilizes screw clamp terminals for secure load and auxiliary connections and is designed to be mounted on DIN rails or fixed via screws, providing versatile installation options.
This contactor ensures high mechanical and electrical durability with an operational endurance of up to 3600 cycles per hour and supports ambient operating temperatures from -5°C up to 60°C. Its compact size, measuring 122mm in length, 55mm in width, and 120mm in depth, allows it to fit into confined control panel spaces.
The device is certified to international standards such as UL, CSA, IEC, CCC, EAC, and Marine certifications, ensuring compliance and safety in global applications. Additionally, it is a Green Premium product from Schneider Electric, compliant with RoHS and REACh, supporting environmental sustainability initiatives.
This contactor supports motor control and resistive loads effectively. Features high reliability and mechanical endurance for industrial cycles. Compact form factor with DIN-rail mounting capability. Includes 3 NO main contacts and 2 auxiliary contacts (1 NO, 1 NC mirror certified).
Certified across multiple international standards for safety and performance. Eco-friendly design compliant with RoHS and REACh regulations. Suitable for various industrial and commercial applications including HVAC and manufacturing.
The Schneider Electric LC1D50AN7 contactor is ideal for integration into motor starters and control systems within industrial manufacturing, HVAC systems, and other commercial applications where robust and reliable switching is required. Its design ensures easy installation, maintenance, and high efficiency in controlling electric motors and resistive loads.
Explore the full range of Contactors and automation control gear at EnvMart to find optimal solutions for your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1D50AN7 contactor has a power rating of 33 kW at 415V.
This model can handle a maximum contact current of 50A.
The coil voltage for this contactor is 400V AC.
The LC1D50AN7 contactor features a 3-pole design.
It operates reliably in temperatures ranging from -5°C to 60°C.
This contactor is designed for DIN rail mounting and can also be fixed via screws.
The contactor includes 2 auxiliary contacts configured as 1 normally open (NO) and 1 normally closed (NC).
It is certified to multiple standards including UL, CSA, IEC, CCC, EAC, and Marine certifications.
The contactor measures 120mm in depth and 55mm in width.
This contactor is designed for motor control and resistive load applications.
The LC1D50AN7 can operate at high rates of up to 3600 cycles per hour.
It utilizes screw clamp terminals for secure load and auxiliary connections.
