MEAN WELL IP67 Dimmable 5 Output LED Driver 48V 60W 1.25A 1 to 10 V PWM Resistance

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 Dimmable 5 Output LED Driver 48V 60W 1.25A 1 to 10 V PWM Resistance

Name: MEAN WELL IP67 Dimmable 5 Output LED Driver 48V 60W 1.25A 1 to 10 V PWM Resistance
Brand: MEAN WELL
SKU: 129089
Price: 20.22 USD
Availability: InStock



Category LED Drivers Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	LPF-60D
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	5
Terminal type	Wire
Maximum Output Power	60W
Input Voltage	305, 90, 127, 431V ac
Output Voltage	48V
Power Dissipation	60W
Standards/Approvals	CB, CE, CSA, EAC, ENEC, SELV, UL
Dimming Operation	1 to 10 V PWM Resistance
Primary Type	AC-DC
Driver Current	1.25A
MEAN WELL, 48V Output, 62.5W Output, 1.3A Output, Constant VoltageBrand	Mean Well

Key Features

IP67 rated for waterproof and dustproof performance.
Built-in 3 in 1 dimming function supporting 1 to 10 Vdc, PWM signal, or resistance.
Universal AC input voltage range and active PFC for high efficiency.
Equipped with protection against short circuit, overload, over voltage, and overheating.
Suitable for LED lighting and moving sign industrial applications.
Fully encapsulated design with free air convection cooling.
Complies with worldwide safety and EMC standards.

Product Description

MEAN WELL LPF-60D-48 is a 60W IP67 waterproof dimmable constant voltage LED driver designed for industrial and commercial LED lighting applications. It provides five outputs with 48V constant voltage and 1.25A driver current, making it ideal for powering multiple LED modules or fixtures simultaneously.

This LED driver offers a fully universal AC input voltage range and incorporates built-in active power factor correction (PFC), ensuring stable and efficient operation with up to 90% efficiency. Its 3 in 1 dimming functionality supports 1 to 10 Vdc dimming control, PWM signals, or resistance dimming, providing versatile lighting dimming options.

The LPF-60D-48 is encased in a fully isolated and sealed plastic enclosure complying with IP67 standards, providing excellent protection against dust and water ingress, suitable for harsh environments. The unit features multiple safety protections including short circuit, overload, over voltage, and over temperature to ensure dependable and safe operation.

This LED driver meets multiple international safety and emission approvals such as CB, CE, CSA, EAC, ENEC, SELV, and UL certifications. Its design complies with UL8750, EN61347-1, and EN61347-2-13 standards, enhancing reliability in LED lighting and moving sign applications.

IP67 encapsulation for robust waterproof and dustproof protection. Built-in 3 in 1 dimming function allowing compatibility with diverse dimming methods. Universal AC input with active PFC for energy efficient operation. Five constant voltage outputs allowing versatile LED configurations.

Multiple built-in protections for enhanced safety and durability. Complies with international standards and electromagnetic compatibility norms. Fully enclosed construction facilitates installation in challenging industrial environments.

This MEAN WELL LED driver series is specifically designed for industrial, commercial LED lighting, signage, and electronic display applications requiring dependable, dimmable constant voltage power supplies with high ingress protection. Its compact, durable design makes it suitable for outdoor and harsh operating conditions.
