Lumberg Minimodul Series Straight Through Hole PCB Header, 8 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 08

Free Delivery in India | Lowest Global Shipping Charges

Lumberg Minimodul Series Straight Through Hole PCB Header, 8 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 08

Name: Lumberg Minimodul Series Straight Through Hole PCB Header, 8 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 08
Brand: LUMBERG
SKU: 129056
Price: 1.01 USD
Availability: InStock



Category PCB Header Brand LUMBERG Condition New

Specifications

Country of Origin	India
Voltage	160V
Brand	Lumberg
Orientation	Straight
Current	5A
Model	2,5 MSF/O 08
Mount Type	Through Hole
Housing Material	Glass Filled Polyamide
Contact Material	Brass
Series	Minimodul
Termination Type	Solder
Maximum Operating Temperature	120°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.5mm
Contact Plating	Tin
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

This PCB header has 8 contacts arranged in a single row for reliable connections.
Constructed with glass-filled polyamide housing for durability and high insulation.
Supports operating temperatures from -40°C to 120°C, suitable for diverse environments.
Rated for a current of up to 5A and voltage up to 160V, fitting low to mid-power circuits.
Designed with solder termination and male contact gender for secure wire connections.
Meets DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards ensuring safety and quality.
Compatible with crimp contact housings (3114 Series) for easy assembly.
Ideal for electronics manufacturing, industrial equipment, and PCB wiring harnesses.

Product Description

Lumberg 2,5 MSF/O 08 Minimodul Series Straight Through Hole PCB Header is a high-quality shrouded connector with 8 male contacts configured in 1 row, featuring a 2.5 mm pitch. It operates safely within a temperature range of -40°C to 120°C and supports currents up to 5A and voltage of 160V, making it suitable for a variety of electronic and industrial applications.

The connector utilizes a glass-filled polyamide housing material for mechanical strength and outstanding electrical insulation. The brass contacts are plated with tin to ensure reliable conductivity and corrosion resistance. This PCB header is designed for through-hole mounting, providing robust solder termination and easy integration into printed circuit boards.

This series mates with compatible crimp contact housings (3114 Series), facilitating effective wire-to-board connections with simplified harnessing for single leads or flat cables. The design supports low and medium volume production runs while maintaining excellent performance and durability.

Certified to international standards including DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11, these headers ensure electrical safety and fire resistance in demanding environments. The straight orientation and shrouded design protect the contacts and provide stable connections.

Shrouded straight through hole PCB header with 8 male contacts. Glass filled polyamide housing ensures durability and insulation. Tin-plated brass contacts offer superior conductivity and corrosion resistance. Rated for 5A current and 160V voltage applications.

Wide operating temperature range from -40°C to 120°C. Meets multiple IEC and DIN safety and performance standards. Compatible with 3114 Series crimp contact housings for wire-to-board connections. Ideal for electronics manufacturing, industrial assemblies, and wiring harnesses.

These PCB Headers are suitable for various industrial, laboratory, electronic assembly, and manufacturing applications demanding reliable, standardized connector solutions. Explore more PCB connectors and headers on EnvMart for expanded electronic system integration options.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model is rated for a current of up to 5A and a voltage of 160V, making it suitable for low to mid-power circuits.

It operates safely within a temperature range of -40°C to 120°C, suitable for diverse environments.

The housing is made from glass-filled polyamide, while the contacts are made of brass and are tin-plated for improved conductivity and corrosion resistance.

This PCB header has 8 male contacts arranged in a single row with a 2.5 mm pitch.

It features a solder termination type, ensuring secure connections during installation.

Yes, it is compatible with the 3114 Series crimp contact housings, allowing for effective wire-to-board connections.

It meets several international standards including DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11, ensuring safety and quality.

This model has a straight orientation, designed for through-hole mounting.

It utilizes a wire-to-board connector system, facilitating reliable connections in electronic assemblies.

The specific weight and dimensions are not provided in the available data; please refer to the manufacturer's specifications for detailed measurements.

It is ideal for electronics manufacturing, industrial equipment, and PCB wiring harnesses, supporting various electronic and industrial applications.

The contact gender for this model is male, designed for secure wire connections.
