RS Pro SPDT Toggle Switch Panel Mount On-Off-On Solder Terminal 24 V dc 240 V ac 7347233P

RS Pro 7347233P is a high-quality SPDT toggle switch designed for panel mounting in electrical, commercial, and industrial equipment. It supports On-Off-On switch operation, allowing versatile control over circuits.

The switch features a robust chromium-plated brass actuator with a length of 5.33 mm, making it durable and resistant to wear and tarnishing. The small panel cutout size of 4.95 mm enables installation in compact spaces.

This toggle switch is rated to handle a contact current of 3 A at 120 V AC, suitable for switching low-power electrical loads safely. Silver-plated brass contacts maintain a low contact resistance of 20 milliohms, thus ensuring reliable electrical connectivity.

Designed to operate reliably in harsh conditions, the switch withstands temperatures ranging from -40°C up to 85°C and provides a mechanical life of approximately 30,000 cycles. It complies with RoHS standards and is lead free, promoting environmentally responsible manufacturing.

The switch employs solder terminal contacts, facilitating secure and lasting wire connections. Its panel mounting configuration makes it easy to install in enclosures, equipment panels, or control devices in automation, telecommunications, computing, and lighting systems.

This toggle switch features a single pole double throw (SPDT) contact configuration. It has a panel mounting design with a cutout diameter of 4.95 mm. The chromium-plated brass actuator provides durability and tarnish resistance.

Rated for 3 A contact current at 120 V AC for reliable performance. Operates within a temperature range from -40°C to +85°C. Silver-plated brass contacts ensure reduced contact resistance of approximately 20 mΩ. Mechanical life expectancy of around 30,000 switching cycles.

The switch is RoHS compliant and lead free for minimal environmental impact. Suitable for industrial, commercial, and automation applications.

This RS Pro toggle switch is manufactured in China and tested to meet stringent quality and performance criteria, making it a trusted component for various electrical and automation projects. Explore more RS Pro Toggle Switches for diverse applications at EnvMart.
