Microchip Digital to Analogue Converter 10 bit 2 Channel SPI 8-Pin PDIP MCP4812-E/P
Specifications
| Country of Origin | Thailand |
|---|---|
| Resolution | 10 bit |
| Brand | Microchip |
| Height | 5.3mm |
| Length | 10.1mm |
| Model | MCP4812-E/P |
| Width | 7.1mm |
| Mount Type | Through Hole |
| Settling Time | 4.5μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Interface Type | SPI |
| Architecture | Resistor String |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
Key Features
- Resistor string architecture ensures reliable DAC conversion.
- Operates within supply voltage range of 2.7V to 5.5V.
- Through hole mount with an 8-pin PDIP package ensuring ease of use in embedded applications.
- Operating temperature range from -40°C to 125°C for industrial-grade performance.
- Fast settling time of 4.5 microseconds enables quick response in signal processing.
- Internal voltage reference for simplified design without external components.
- Suitable for use in industrial, electronic instrumentation and embedded systems applications.
Product Description
The Microchip MCP4812-E/P is a high-performance digital to analogue converter (DAC) featuring 10-bit resolution and two output channels. It utilizes a resistor string architecture to provide accurate analogue voltage outputs through a Serial Peripheral Interface (SPI) communication protocol.
Designed in an 8-pin PDIP through-hole package, this DAC supports supply voltages ranging from 2.7 to 5.5 volts, allowing flexible integration into diverse electronic circuits. Its wide operating temperature range from -40°C to 125°C ensures reliable operation in demanding industrial, commercial, and embedded environments.
With a settling time of just 4.5 microseconds and an internal voltage reference, the MCP4812-E/P offers both speed and design simplicity, reducing the need for additional components. The device’s compact dimensions (10.1mm length × 7.1mm width × 5.3mm height) make it suitable for space-constrained applications.
This converter is ideal for electronics instrumentation, signal processing, and control systems in industrial automation where precise analogue voltage outputs are required. The product is manufactured in Thailand and complies with standard semiconductor quality expectations.
Resistor string architecture for high accuracy DAC output. 10-bit resolution enables fine analogue granularity. Dual output channels increase functional versatility. SPI interface simplifies digital control integration. Wide supply and operating temperature range for industrial-grade use.
Compact 8-pin PDIP package designed for through-hole mounting. Fast 4.5 μs settling time supports rapid signal changes. Internal voltage reference streamlines circuit design. Explore more Digital to Analogue Converters and semiconductor components in the Electronics & Electricals category on EnvMart for reliable industrial and electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP4812-E/P features a resolution of 10 bits, allowing for fine analogue granularity in its output.
It operates within a supply voltage range of 2.7V to 5.5V, providing flexibility for integration into various electronic circuits.
This model has dimensions of 10.1mm in length, 7.1mm in width, and 5.3mm in height, making it suitable for space-constrained applications.
The device features two output channels, increasing its functional versatility for various applications.
The MCP4812-E/P has a fast settling time of 4.5 microseconds, supporting rapid signal changes in processing.
It can operate at a maximum temperature of 125°C, ensuring reliable performance in demanding environments.
This digital to analogue converter utilizes a Serial Peripheral Interface (SPI) for digital control integration.
It employs a resistor string architecture, which ensures reliable and accurate DAC conversion.
The minimum operating temperature for the MCP4812-E/P is -40°C, making it suitable for industrial-grade applications.
This model is designed for through-hole mounting, which facilitates ease of use in embedded applications.
The product is manufactured in Thailand, adhering to standard semiconductor quality expectations.
It provides an analogue voltage output, suitable for various applications in signal processing and control systems.
