TE Connectivity Buchanan Series 3-Contact 5.08 mm Pitch 1 Row Pluggable Terminal Block 796638-3
Specifications
| Country of Origin | Italy |
|---|---|
| Voltage | 300V |
| Brand | TE Connectivity |
| Colour | Green |
| Orientation | Right Angle |
| Current | 15A |
| Model | 796638-3 |
| Housing Material | Polyamide |
| Series | Buchanan |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 3 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3mm² |
| Minimum Wire Size AWG | 12AWG |
| Maximum Wire Size AWG | 30AWG |
| Wire Connection Method | Solder |
Key Features
- Supports up to 15A current for efficient power handling.
- Constructed from durable green polyamide housing ensuring toughness and insulation.
- Accommodates wire sizes from 0.05 mm² to 3 mm² and AWG 12 to AWG 30 for versatile wiring applications.
- Right angle orientation facilitates compact PCB mounting and optimized layouts.
- Solder wire connection method ensures secure and stable electrical contacts.
- Designed with female connector gender suitable for pluggable connections.
- Operates at a rated voltage of 300V, meeting typical industrial and electronic requirements.
- Manufactured in Italy under the Buchanan series by TE Connectivity.
Product Description
TE Connectivity 796638-3 is a high-quality pluggable terminal block designed for demanding industrial and electronic applications, featuring 3 contacts arranged in a single row with a 5.08 mm pitch. This component is engineered to support a current rating of 15A and a voltage rating of 300V, making it suitable for a wide range of power and signal wiring tasks.
The housing is made from durable green polyamide (Polyamide 6.6 GF), which provides excellent electrical insulation and mechanical stability. Its right angle orientation enables efficient PCB mounting and space-saving layouts, ideal for compact electronic assemblies and industrial control panels.
The connector employs a solder wire connection method, accommodating wire sizes ranging from 0.05 mm² up to 3 mm², and corresponding AWG sizes from 12 to 30. The female connector gender supports pluggable mating, facilitating easy and reliable connections and disconnections for maintenance or upgrades.
This terminal block complies with UL 94V-0 flame retardancy standards, ensuring safety in electrical installations. Manufactured in Italy by TE Connectivity, this terminal block belongs to the Buchanan series known for its reputable performance and quality in the electronics industry.
Ideal use cases include industrial automation, circuit connection, power distribution boards, electronic instrumentation, and PCB terminal applications requiring dependable and easy-to-install connectors.
Supports up to 15A current for efficient power handling. Durable polyamide housing ensures electrical insulation and mechanical strength. Right angle orientation for efficient PCB layout and mounting. Solder wire connection method for secure electrical contacts.
Compatible with wire sizes from 0.05 mm² to 3 mm² and AWG 12 to AWG 30. Rated for 300V operational voltage. Green color coding aids in easy identification. Part of TE Connectivity's trusted Buchanan series. Explore more electronic components and Pluggable Terminal Blocks at EnvMart for your industrial, electronic, and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a current rating of 15A, making it suitable for efficient power handling in various applications.
It operates at a rated voltage of 300V, meeting typical industrial and electronic requirements.
It accommodates wire sizes ranging from 0.05 mm² to 3 mm² and AWG sizes from 12 to 30, providing versatility for various wiring applications.
This model features a right angle orientation, which facilitates compact PCB mounting and optimized layouts.
The housing is constructed from durable green polyamide, which ensures electrical insulation and mechanical stability.
It has 3 contacts arranged in a single row, designed for efficient electrical connections.
It employs a solder wire connection method, ensuring secure and stable electrical contacts.
The terminal block is green in color, which aids in easy identification during installation and maintenance.
It is manufactured in Italy, ensuring adherence to quality standards in production.
This model is part of the Buchanan series by TE Connectivity, known for its reputable performance in the electronics industry.
It is ideal for use in industrial automation, circuit connection, power distribution boards, and electronic instrumentation.
The pitch size is 5.08 mm, which is standard for many pluggable terminal block applications.
