Preci-Dip 803 Series Straight PCB PCB Socket 6-Contact 2 Row 2.54 mm Pitch Solder 803-87-006-10-012101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Provides reliable electrical connection with beryllium copper alloy contacts.
- Features gold flash plating for enhanced conductivity and corrosion resistance.
- Constructed with black glass filled polyester housing for durability.
- Operates within a voltage rating of 150V and current rating of 12A.
- Suitable for operating temperatures from -55°C to 125°C.
- Designed for solder termination on printed circuit boards.
- Facilitates efficient assembly in electronic manufacturing applications.
- Compact design with 2.54 mm pitch and 6 contacts in 2 rows.
Product Description
Preci-Dip 803-87-006-10-012101 is a high-quality straight PCB socket designed for electronic board-to-board connections. It features 6 female contacts arranged in 2 rows with a precise 2.54 mm pitch, allowing reliable mating and electrical conductivity for various electronic components and modules.
The socket housing is manufactured from durable black glass filled polyester, providing excellent mechanical stability and chemical resistance in industrial and laboratory environments. The contacts are made of beryllium copper alloy, which ensures high conductivity and mechanical resilience.
This PCB socket supports solder termination, making it suitable for through-hole mounting on printed circuit boards. Its gold flash plating enhances corrosion resistance and maintains strong electrical contact over time. The product is rated for 12 amps current and operates safely within voltages up to 150 volts, making it ideal for a variety of electronic assembly applications in industrial, manufacturing, and electronic testing setups.
Operating temperatures range from -55°C to 125°C, allowing stable performance even in harsh environmental conditions where temperature fluctuations occur. Reliable 6-contact, 2 row configuration with 2.54 mm pitch. Beryllium copper alloy contacts with gold flash plating.
Black glass filled polyester housing ensures robust mechanical properties. Solder termination type designed for PCB mounting. Current rating of 12A and voltage rating of 150V suitable for industrial electronics. Operating temperature from -55°C to 125°C for wide environmental tolerance.
Straight orientation facilitates easy board-to-board connection. Made in Switzerland ensuring premium manufacturing standards.
This Preci-Dip PCB Socket series is widely used in electronics manufacturing, testing laboratories, and embedded systems, providing dependable electrical connections in compact form factors. It supports automated assembly lines to improve production efficiency.
Explore our extensive range of PCB connectors and sockets at EnvMart to meet your electronic component sourcing requirements with quality and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PCB socket has a voltage rating of 150V and a current rating of 12A.
It features a housing made from black glass filled polyester and contacts made of beryllium copper alloy with gold flash plating.
The operating temperature range is from -55°C to 125°C.
This socket has 6 female contacts arranged in 2 rows.
The pitch of the contacts is 2.54 mm.
It uses a solder termination type for PCB mounting.
The socket has a straight orientation, facilitating easy board-to-board connections.
This model is manufactured in Switzerland.
It is suitable for various electronic assembly applications in industrial, manufacturing, and electronic testing setups.
The gold flash plating enhances conductivity and provides corrosion resistance for the contacts.
The connector system is designed for board-to-board connections.
Yes, it supports automated assembly lines to improve production efficiency.
