Preci-Dip 800 Series Right Angle Through Hole Pin Header, 5 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 800-80-005-20-001101

Preci-Dip 800-80-005-20-001101 is a precision-engineered Right Angle Through Hole Pin Header from the 800 Series designed for PCB interconnections in demanding industrial and electronic applications. This connector features 5 male pins arranged in a single row with a standard 2.54 mm pitch, making it suitable for a wide variety of electronic assemblies and circuit configurations.

The housing is made from fibreglass reinforced polyethylene terephthalate, providing robust mechanical strength and excellent insulation properties. Brass contact pins with tin plating ensure low contact resistance and reliable electrical conduction under continuous usage. The right-angle orientation supports versatile PCB layout designs, and the through hole mount ensures stable mechanical connection with solder termination.

This pin header is rated to handle up to 3 amperes of current and a voltage of 150 volts, operating reliably within a temperature range of -55°C to 125°C, suitable for industrial, laboratory, commercial, and manufacturing environments. The pins have a tail length of 3.2 mm facilitating efficient soldering processes in automated and manual soldering setups.

The product is unshrouded to allow easy access for assembly and testing, ideal for applications requiring quick or repeated manual intervention. The compact design with 5 contacts and 2.54 mm pitch is compatible with many standard PCB designs, supporting effective signal and power transmission.

Constructed from fibreglass reinforced polyethylene terephthalate housing for enhanced durability and insulation. Features brass pins with tin plating for reliable electrical contact and corrosion resistance. Designed for through hole mounting with right-angle pin orientation to optimize PCB space.

Rated for 3A current and 150V voltage, supporting strong electrical performance. Operates from -55°C to 125°C, suitable for harsh environmental conditions. Unshrouded design eases access for assembly and maintenance. Single row of 5 male contacts with 2.54 mm pitch ensures compatibility with common PCB layouts.

Tail length of 3.2 mm provides stable solder joints for reliability. Manufactured in Switzerland, meeting high-quality standards.

This Preci-Dip 800 Series Right Angle Through Hole Pin Header is widely used in industrial control systems, communication equipment, measurement instruments, and electronics manufacturing, providing dependable connectivity solutions. For further product selections, explore the extensive range of PCB Headers available at EnvMart for your industrial and commercial needs.
