HARTING D-Sub Straight Cable D-Sub Connector Male 15 Signal, 5A, 1000V, Steel Housing, Model 09693120172

HARTING 09693120172 D-Sub Straight Cable D-Sub Connector Male is a high-quality electrical connector designed for secure and reliable cable connections in industrial and electronic applications. Its straight cable mount design and male connector gender make it ideal for mixed signal transmissions where 15 signal contacts are required.

This connector supports a current of 5A and can withstand operating voltages up to 1000V, catering to medium power electronic devices and control systems. The contacts are crafted from copper alloy with tin plating providing excellent conductivity and corrosion resistance, while the steel housing offers robust mechanical protection ensuring durability even in rugged environments.

Designed in compliance with RoHS and DIN 41 652 T1 standards, the connector is suitable for use in a wide temperature range from -55°C to 125°C, making it reliable for use in industrial, manufacturing, automotive, and telecommunications equipment. Its crimp termination type ensures a stable and secure electrical contact with cables.

The product is an ideal solution for electronics component assemblies, power and signal connectors, and for installations requiring high-performance connectors with long service life and environmental resilience.

Features include mixed contact layout 17W2, flange-through hole of 3.1 mm, and tinned metal shell enhancing the connector’s mechanical stability and ease of installation. The connector is tailored for applications in power distribution and electronic component sectors.

Designed for crimp termination ensuring secure contact connection. Supports a current rating of 5A for standard signal transmissions. Operates at voltages up to 1000V suitable for various industrial applications. Tinned copper alloy contacts provide effective conductivity and corrosion resistance.

Suitable for cable mounting with straight orientation male connector design. Housing made of durable steel for mechanical protection. Meets RoHS compliance and DIN 41 652 T1 standards for quality assurance. Temperature range from -55°C to 125°C for reliable performance in harsh environments.

Contact plating is tin to maintain signal integrity.

This HARTING D-Sub Connector enhances system performance by providing stable, high-quality electrical connections vital for electronic, laboratory, manufacturing, and telecommunications applications. EnvMart offers this model with full confidence in its industrial-grade reliability and compliance.
