STMicroelectronics Voltage Regulator Linear 30V 1.5A Surface Mount 3-Pin LD1086DT18TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators STMicroelectronics LD1086DT18TR, Voltage Regulator 30V 3-Pin RS Stock |
| Brand | STMicroelectronics |
| Height | 2.4mm |
| Length | 6.6mm |
| Model | LD1086DT18TR |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | LD1086 |
| Maximum Operating Temperature | 125°C |
| Polarity | Positive |
| Maximum Input Voltage | 30V |
| Quiescent Current | 5mA |
| Pin Count | 3 |
| Automotive Standard | AEC-Q100 |
Key Features
- Offers a maximum input voltage of 30 volts for flexible application.
- Integrated internal current limiting and thermal shutdown for enhanced protection.
- Surface mount with compact dimensions of 6.6mm length, 6.2mm width, and 2.4mm height.
- Positive polarity design ensures correct voltage regulation in standard circuits.
- Quiescent current is low at 5mA to optimize power efficiency.
- Certified to automotive standard AEC-Q100 for reliability.
- Maximum operating temperature up to 125°C suitable for demanding environments.
- Designed for use in power management IC applications in electronic components and semiconductors.
Product Description
STMicroelectronics LD1086DT18TR is a high-performance linear voltage regulator designed to provide regulated output voltage up to 30 volts with a maximum load current of 1.5 amperes. Featuring a compact surface mount 3-pin package, it is ideal for applications requiring efficient power management in compact electronic devices.
This voltage regulator includes built-in current limiting and thermal shutdown functionality, which protects the device and connected circuits from damage under overload or thermal stress conditions. Its low quiescent current of 5mA contributes to overall power efficiency, making it suitable for battery-powered and low-power devices.
The device measures 6.6mm in length, 6.2mm in width, and 2.4mm in height, providing a small footprint for PCB designs. It has a high maximum operating temperature rating of 125°C and meets the automotive quality standard AEC-Q100, ensuring reliability in automotive and industrial environments.
This regulator is designed primarily for use in power management IC applications within electronics and semiconductor devices. Its surface mount package simplifies automated assembly processes, improving production efficiency in industrial manufacturing.
Maximum input voltage of 30 volts enables flexible voltage regulation. 3-pin surface mount package designed for compact installations. Built-in internal current limiting and thermal shutdown safeguard device operation. Low quiescent current of 5mA reduces power consumption.
Complies with AEC-Q100 automotive standards for high reliability. Compact size ideal for integration into tight PCB layouts. Operates at maximum temperature up to 125°C for harsh environments. Effective for power management in electronic and semiconductor applications.
The STMicroelectronics LD1086DT18TR voltage regulator is suitable for industrial, automotive, consumer electronics, and laboratory equipment requiring stable and efficient voltage regulation. Its durability and compliance with automotive standards make it ideal for use in demanding applications where safety and reliability are critical.
Explore a wide range of power management ICs and Voltage Regulators in the Electronics & Electricals category on EnvMart to find complementary components and related products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input voltage for the LD1086DT18TR voltage regulator is 30 volts, allowing for flexible application in various electronic circuits.
This voltage regulator can handle a maximum load current of 1.5 amperes, making it suitable for a range of power management applications.
The dimensions of this model are 6.6mm in length, 6.2mm in width, and 2.4mm in height, making it compact for surface mount applications.
The quiescent current for the LD1086DT18TR is low at 5mA, which helps optimize power efficiency in electronic devices.
The maximum operating temperature for the LD1086DT18TR is 125°C, suitable for use in demanding environments.
Yes, it includes built-in current limiting and thermal shutdown features to protect the device and connected circuits from overload or thermal stress.
This model uses a surface mount design, which simplifies automated assembly processes in manufacturing.
The LD1086DT18TR is certified to the automotive standard AEC-Q100, ensuring reliability in automotive applications.
It features a positive polarity design, ensuring correct voltage regulation in standard circuits.
This voltage regulator is designed for use in power management IC applications within electronics, semiconductors, industrial, automotive, and consumer electronics.
The LD1086DT18TR has a 3-pin configuration, ideal for compact installations on PCBs.
The country of origin for this voltage regulator is India.
