HARWIN M30 Series Straight Surface PCB Header 6 Contact 1.25 mm Pitch 1 Row Shrouded M30-6000646
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 150V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 1A |
| Model | M30-6000646 |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | M30 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.3mm |
Key Features
- Constructed with a durable nylon housing for insulation.
- Brass contact material with tin plating ensures reliable electrical connection.
- Surface mount type with straight orientation for easy PCB integration.
- Operates within a temperature range of -25°C to 85°C for versatile use.
- Tail pin length is 2.3 mm allowing secure solder termination.
- Shrouded connector protects contacts from accidental shorts and damage.
- Ideal for wire-to-board connector systems in electronic devices.
- Manufactured in Japan ensuring high-quality standards.
Product Description
HARWIN's M30-6000646 is a high-quality M30 Series Straight Surface PCB Header designed with 6 contacts arranged in a single row and a pitch of 1.25 mm. Featuring a shrouded housing made from robust nylon, it ensures excellent insulation and reliability for electronic connections.
The connector system is specifically engineered for wire-to-board applications, providing a secure and stable connection via solder termination with a tail pin length of 2.3 mm. Brass contacts with tin plating facilitate efficient electrical conductivity and corrosion resistance.
Operating reliably across temperatures from -25°C to 85°C, and supporting a voltage rating of 150V along with a current capacity of 1A, this PCB header is suitable for a wide range of moderate power electronics.
The straight orientation and surface mount type enable easy mounting on PCBs with optimized space usage. The shrouded design protects contacts from damage and prevents accidental shorts, enhancing durability and safety in electronics assembly.
Manufactured in Japan, this connector meets rigorous quality standards and is designed to mate with M30-110 Series housings for versatile integration. Its compact 1.25 mm pitch allows use in dense PCB layouts, making it ideal for industrial, electronic manufacturing, equipment repair, and development applications.
Constructed with a durable nylon housing for insulation. Brass contact material with tin plating ensures reliable electrical connection. Surface mount type with straight orientation for easy PCB integration. Rated voltage of 150V and current capacity of 1A for moderate power applications.
Operates within a temperature range of -25°C to 85°C for versatile use. Tail pin length is 2.3 mm allowing secure solder termination. Shrouded connector protects contacts from accidental shorts and damage. Ideal for wire-to-board connector systems in electronic devices.
Manufactured in Japan ensuring high-quality standards. Compact pitch of 1.25 mm suitable for dense PCB layouts. Explore more PCB Headers and electronic components in the Electronics & Electricals category at EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M30-6000646 PCB header has a voltage rating of 150V, making it suitable for moderate power applications.
This model supports a current capacity of 1A, allowing it to handle moderate power requirements in electronic devices.
It operates within a temperature range of -25°C to 85°C, providing versatility for various applications.
The housing is made from durable nylon, while the contacts are made of brass with tin plating for reliable electrical connection.
The HARWIN M30-6000646 features 6 contacts arranged in a single row, designed for efficient connectivity.
This model has a compact pitch of 1.25 mm, suitable for dense PCB layouts.
It uses solder termination with a tail pin length of 2.3 mm, ensuring secure connections on PCBs.
This unit is a surface mount type, allowing for easy integration onto printed circuit boards.
The HARWIN M30-6000646 features a straight orientation, facilitating straightforward PCB integration.
It is designed for wire-to-board applications, providing stable connections for electronic devices.
This product is manufactured in Japan, ensuring adherence to high-quality standards.
The shrouded design protects contacts from accidental shorts and damage, enhancing reliability in electronic assemblies.
