HARWIN M30 Series Straight Surface PCB Header, 4 Contacts, 1.25 mm Pitch, 1 Row, Shrouded M30-6000446

HARWIN M30-6000446 is a Straight Surface PCB Header designed for electronic applications requiring precise and reliable wire-to-board connections. It features a robust nylon housing that offers excellent durability and electrical insulation, making it suitable for diverse industrial and electronic equipment assemblies.

This model includes 4 male brass contacts plated with tin to ensure effective conductivity and resistance against corrosion. The standard pitch of 1.25 mm and single row configuration enable compact PCB design and efficient assembly. The header is designed for surface mounting with soldering termination for enhanced mechanical stability on circuit boards.

Operating safely at up to 1A current and voltage ratings of 150V, it is engineered for applications in electronics manufacturing, industrial control systems, and embedded devices. The operating temperature range of -25°C to 85°C ensures performance reliability in standard industrial and commercial environments.

The shrouded connector system provides extra protection for contacts and aids in correct orientation when mating with compatible connectors, specifically the M30-110 series housings. With a tail pin length of 2.3 mm, secure solder joints and consistent electrical contact are achieved.

This PCB header is ideal for use in electronic component manufacturing, laboratory assemblies, automation equipment, and other industrial electronic applications that require stable and durable headers for wire-to-board connections.

This PCB Header features a nylon housing that ensures durability and insulation. It has 4 brass contacts plated with tin for good conductivity and corrosion resistance. The connector system is wire-to-board with a surface mount type facilitating easy soldering.

The contact gender is male with a tail pin length of 2.3 mm optimized for solid electrical connection. This header operates safely at currents up to 1A and voltages up to 150V. It functions within a temperature range from -25°C to 85°C, suitable for various industrial environments.

The shrouded design enhances connector protection and polarisation during mating. It mates with M30-110 series housings and supports reliable PCB mounting and electrical performance.
