Texas Instruments Operational Amplifier, 3 MHz GBP, 8-Pin SOIC, Dual Channel, 18V LF412CDR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | LF412CDR |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LF412C |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | -18V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | 4 nA |
| Vos - Input Offset Voltage | 3 mV |
| Slew Rate | 13V/μs |
| Input Offset Current | 2 nA |
Key Features
- Features a gain bandwidth product of 3 MHz for high-speed amplification.
- Operates with dual channels in an 8-pin SOIC package for surface mounting.
- Input offset voltage is low at 3 mV to ensure signal accuracy.
- Wide supply voltage range from -18 V to 18 V supports flexible operation.
- Slew rate of 13 V/μs enables fast response to signal changes.
- Supports operating temperature range from 0°C to 70°C for reliability in various environments.
- JFET input type ensures high input impedance and low bias currents.
- Ideal for electronics, industrial controls, instrumentation, and signal processing applications.
Product Description
Texas Instruments LF412CDR is a high-performance operational amplifier featuring a gain bandwidth product of 3 MHz, designed for precise analog signal amplification. It comes in an 8-pin SOIC package optimized for surface mounting and dual channel operation.
This operational amplifier has a minimum supply voltage rating of -18 V and a maximum of 18 V, making it versatile for different power configurations. It offers a low input offset voltage of 3 mV and minimal input bias current of 4 nA, contributing to stable, accurate amplification even in sensitive circuits.
The device features a slew rate of 13 V/μs, which allows rapid output voltage changes, essential for high-frequency applications and reducing signal distortion. Its operating temperature range from 0°C to 70°C ensures dependable performance in ambient industrial and laboratory environments.
The LF412CDR's JFET input configuration provides high input impedance and low noise, making it suitable for audio processing, instrumentation, and control systems. Package dimensions enable facile PCB layout in compact systems.
Gain bandwidth product of 3 MHz supporting fast analog response. Eight pins in an SOIC package for dual-channel surface mount installations. Low offset voltage and bias current for precision amplification. Wide +/-18 V supply range for flexible powering.
Slew rate of 13 V/μs for rapid signal transitions. Temperature rated 0°C to 70°C for rugged use cases. JFET input stage improves input impedance and noise performance. Compact form factor measuring 4.9 mm x 3.91 mm x 1.58 mm.
This Operational Amplifier is ideal for industrial electronics, instrumentation, audio processing, and other applications demanding reliable low-noise amplification. Explore more electronics components and amplifiers on EnvMart for your precision circuit design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LF412CDR features a gain bandwidth product of 3 MHz, which supports high-speed amplification.
This model operates with a supply voltage range from -18 V to 18 V, allowing for flexible power configurations.
The input offset voltage of the LF412CDR is low at 3 mV, contributing to accurate signal amplification.
It has a slew rate of 13 V/μs, enabling fast response to signal changes, which is essential for high-frequency applications.
The operational amplifier operates within a temperature range of 0°C to 70°C, ensuring reliability in various environments.
This model features dual channels, allowing for simultaneous signal amplification.
The package dimensions of the LF412CDR are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
It utilizes a JFET input type, which provides high input impedance and low bias currents.
The input bias current of the LF412CDR is 4 nA, which helps in maintaining signal integrity.
This operational amplifier comes in an 8-pin SOIC package, optimized for surface mounting.
The LF412CDR is part of the LF412C series of operational amplifiers from Texas Instruments.
It is ideal for use in electronics, industrial controls, instrumentation, and signal processing applications.
