Vishay 40 V 15 A Surface Mount Schottky Rectifier 3-Pin TO-263 Package VS-12TQ040S-M3
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 10.67mm |
| Brand | Vishay |
| Height | 4.83mm |
| Length | 10.67mm |
| Model | VS-12TQ040S-M3 |
| Width | 9.65mm |
| Mount Type | Surface |
| Series | 12TQ-SPbF |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS, IEC 61249-2-21 |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 15A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1.75mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 990A |
| Maximum Forward Voltage Vf | 0.56V |
Key Features
- Surface mount device with TO-263 package ensuring compact design.
- Maximum continuous forward current of 15 A suitable for high current applications.
- Peak reverse repetitive voltage rated at 40 V for reliable operation.
- Low maximum forward voltage of 0.56 V reduces power dissipation.
- Extends operating temperature range from -55°C up to 150°C.
- Fast switching with peak reverse current as low as 1.75 mA.
- Configured as a single diode with 3 pins for easy PCB integration.
- Peak non-repetitive forward surge current capability of 990 A for transient conditions.
Product Description
Vishay VS-12TQ040S-M3 is a surface mount Schottky rectifier diode designed for applications requiring efficient, fast switching and minimal power loss. It features a TO-263 3-pin package suitable for high current and low forward voltage applications with a maximum operating temperature of 150°C.
Its 15 A maximum continuous forward current and 40 V peak reverse voltage make it a robust choice for power electronics, DC-DC converters, and power supplies. The low forward voltage drop of 0.56 V reduces energy dissipation and improves efficiency especially in battery-powered and automotive electronics.
The diode’s fast recovery characteristics and peak surge capability of 990 A ensure reliable operation during transient conditions. This Schottky rectifier complies with RoHS and IEC 61249-2-21 standards and meets automotive-grade AEC-Q101 standards, making it suitable for use in demanding industrial and automotive applications.
Typical industries utilizing this device include power management in industrial automation, HVAC systems, consumer electronic devices, automotive electronics, and telecommunications equipment.
Surface mount device with TO-263 package ensuring compact design. Maximum continuous forward current of 15 A suitable for high current applications. Peak reverse repetitive voltage rated at 40 V for reliable operation. Low maximum forward voltage of 0.56 V reduces power dissipation.
Extends operating temperature range from -55°C up to 150°C. Fast switching with peak reverse current as low as 1.75 mA. Configured as a single diode with 3 pins for easy PCB integration. Peak non-repetitive forward surge current capability of 990 A for transient conditions.
Compliant with RoHS and IEC 61249-2-21 standards assuring quality and environmental safety. Automotive grade with AEC-Q101 certification for demanding vehicle electronics. Explore more Vishay semiconductor products and Schottky diodes on EnvMart to find the right solution for your electronic component needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-12TQ040S-M3 is 15 A.
The maximum forward voltage drop is 0.56 V, which helps reduce power dissipation.
The operating temperature range extends from -55°C to 150°C.
This model is configured as a single diode with 3 pins for easy PCB integration.
It has a peak non-repetitive forward surge current capability of 990 A.
This rectifier uses a TO-263 package type, suitable for surface mount applications.
It complies with RoHS and IEC 61249-2-21 standards, and meets automotive-grade AEC-Q101 standards.
The dimensions are 10.67 mm in diameter, 4.83 mm in height, and 9.65 mm in width.
This model is commonly used in power management for industrial automation, HVAC systems, consumer electronics, automotive electronics, and telecommunications equipment.
The country of origin for the Vishay VS-12TQ040S-M3 is India.
