NXP 8 bit S08 HCS08 Microcontroller 40 MHz 32kB FLASH 44-Pin QFP MC9S08GT32ACFBE

Free Delivery in India | Lowest Global Shipping Charges

NXP 8 bit S08 HCS08 Microcontroller 40 MHz 32kB FLASH 44-Pin QFP MC9S08GT32ACFBE



Category Microcontroller Brand NXP Condition New

Specifications

Country of Origin	India
Brand	NXP
Height	2mm
Length	10mm
Model	MC9S08GT32ACFBE
Width	10mm
Mount Type	Surface
Series	HCS08
Maximum Operating Temperature	85°C
Package Type	QFP
Minimum Operating Temperature	-40°C
Ram size	2kB
Interface Type	SCI, SPI
Standards/Approvals	RoHS
Pin Count	44
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Maximum Power Dissipation Pd	800mW
Minimum Supply Voltage	1.8V
Device Core	S08
Program Memory Size	32kB
Maximum Clock Frequency	40MHz
Number of Programmable I/Os	36
Analogue Comparators	2
Number of Timers	2
Instruction Set Architecture	CISC
ADCs	8 x 10 Bit
Program Memory Type	FLASH
DACs	1 x 5 Bit

Key Features

The microcontroller operates on an S08 core with an 8-bit data bus width.
It supports SCI and SPI interface types for versatile communication.
The device includes 2kB of RAM and 32kB of program FLASH memory.
Maximum supply voltage is 5.5V with a programmable internal clock generator.
Operating temperature range is from -40°C to 85°C, suitable for automotive applications.
Includes features like 1 x 5-bit DAC, 8 x 10-bit ADCs, 2 analogue comparators, and 2 timers.
Designed with RoHS compliant materials and meets AEC-Q100 automotive standard.
Compact dimension of 10mm by 10mm by 2mm in a surface mount QFP package.

Product Description

NXP MC9S08GT32ACFBE 8 bit S08 HCS08 Microcontroller operates at 40 MHz and includes 32kB of FLASH memory packed in a 44-Pin QFP package. This surface mount microcontroller integrates an S08 core architecture with CISC instruction set for high performance and low power consumption.

It supports versatile interfaces such as SCI and SPI, suitable for embedded applications requiring robust communication protocols. The device features 2kB RAM, 1 x 5-bit DAC, 8 x 10-bit ADCs, 2 analogue comparators, and 2 timers offering extensive peripheral integration.

The microcontroller operates over a wide temperature range from -40°C to +85°C, making it suitable for automotive and industrial applications. Compliance with RoHS and AEC-Q100 ensures reliability and environmental safety, reinforcing its suitability for stringent automotive standards.

Compact dimensions of 10mm length, 10mm width, and 2mm height in a 44-pin QFP package contribute to easy PCB integration in constrained spaces. It has a maximum supply voltage of 5.5V and maximum power dissipation of 800mW. The internal programmable clock generator with temperature and voltage compensation ensures stable operations.

The microcontroller’s 8-bit data bus width supports efficient processing. SCI and SPI interfaces offer versatile connectivity options. Includes analog features such as DAC and ADC units for mixed-signal processing. Designed with automotive-grade reliability standards (AEC-Q100).

Compact and lightweight surface mount package suitable for high-density boards.

This microcontroller is ideal for a broad range of industrial, automotive, embedded control, and consumer electronics applications where dependable, low-power performance is needed. Explore the NXP Microcontroller range in the Electronics & Electricals category for advanced semiconductor solutions.
