NXP 16 bit HSC12 HCS12 Microcontroller 25 MHz 128kB FLASH 112-Pin LQFP MC9S12DG128CPVE
Specifications
| Country of Origin | India |
|---|---|
| Brand | NXP |
| Height | 1.45mm |
| Length | 20mm |
| Model | MC9S12DG128CPVE |
| Width | 20mm |
| Mount Type | Surface |
| Series | HCS12 |
| Maximum Operating Temperature | 85°C |
| Package Type | LQFP |
| Minimum Operating Temperature | -40°C |
| Ram size | 8kB |
| Interface Type | MEBI, SPI, SCI |
| Standards/Approvals | RoHS |
| Pin Count | 112 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | -0.3V |
| Device Core | HSC12 |
| Program Memory Size | 128kB |
| Maximum Clock Frequency | 25MHz |
| Number of Programmable I/Os | 8 |
| Number of Timers | 1 |
| Instruction Set Architecture | MCU |
| ADCs | 8 x 10 Bit |
| Program Memory Type | FLASH |
Key Features
- This microcontroller features a 112-Pin LQFP surface mount package for compact integration.
- It supports multiple interfaces including MEBI, SPI, and SCI for versatile communication.
- Equipped with 8kB RAM, 8x 10-bit ADCs, and pulse-width modulators for advanced control tasks.
- Operates reliably over a temperature range from -40°C to 85°C and voltage range from -0.3V to 6V.
- Designed to meet RoHS compliance and automotive standard AEC-Q100 for quality assurance.
- Includes on-chip peripherals like timers, EEPROM, serial interfaces, and CAN compatible modules.
- Offers flexibility for power consumption and performance with an integrated PLL circuit.
- Ideal for embedded automotive, industrial control, and electronic device applications.
Product Description
The NXP MC9S12DG128CPVE is a 16 bit HSC12 series microcontroller, incorporating a high-performance 25 MHz HCS12 CPU core with 128kB of Flash memory and 8kB of RAM. It comes in a compact 112-Pin Low-profile Quad Flat Package (LQFP) designed for surface mounting, making it well-suited for automotive and industrial embedded system designs.
This microcontroller offers various integrated peripherals including two asynchronous serial communication interfaces (SCI), a serial peripheral interface (SPI), and an inter-IC bus (MEBI), enabling flexible connectivity and control options. Its on-chip 8-channel, 10-bit ADCs, pulse-width modulators, timers, and EEPROM provide comprehensive capabilities for sensor interfacing and precise control mechanisms.
The device is designed to operate over a wide voltage range of -0.3V to 6V and a broad temperature range from -40°C to 85°C, ensuring robust operation in harsh automotive and industrial environments. It conforms to the automotive AEC-Q100 standard and is RoHS compliant for environmental safety.
The integrated PLL circuitry offers optimized power consumption versus performance trade-offs, suitable for applications requiring energy efficiency without compromising processing speed. This microcontroller supports automotive CAN software compatibility and includes modules for byteflight data protocols.
Typical applications include automotive engine control units, industrial automation controllers, and advanced electronic systems that demand reliability, high integration, and flexible interfacing options.
This microcontroller features a 112-Pin LQFP surface mount package for compact integration. Supports interfaces such as MEBI, SPI, and SCI for multiple communication protocols. Includes 8kB RAM and 8x 10-bit ADC channels for analog and digital signal processing.
Operates within temperature range of -40°C to 85°C and voltage range of -0.3V to 6V. RoHS compliant and meets automotive standard AEC-Q100. Equipped with timers, pulse-width modulators, EEPROM, and CAN compatible modules.
Integrated PLL circuit allows power-performance flexibility. Suitable for automotive, industrial control, and embedded applications. Explore the comprehensive range of Microcontrollers at EnvMart for advanced industrial and automotive electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of the NXP MC9S12DG128CPVE microcontroller is 25 MHz.
It features a program memory size of 128kB FLASH.
This microcontroller supports multiple communication interfaces including MEBI, SPI, and SCI.
The operating temperature range is from -40°C to 85°C.
The unit includes 8kB of RAM.
It comes in a 112-Pin Low-profile Quad Flat Package (LQFP).
The microcontroller operates within a voltage range of -0.3V to 6V.
Yes, it is designed to meet the automotive standard AEC-Q100.
It includes on-chip peripherals such as timers, EEPROM, and 8-channel 10-bit ADCs.
The height is 1.45mm, and the width is 20mm.
This microcontroller is suitable for applications in automotive engine control units, industrial automation controllers, and advanced electronic systems.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
