Murata EMI Filter 10V DC 50MHz 20mA 0805 Surface Mount Solder NFA21SL
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 0.85mm |
| Length | 2mm |
| Model | NFA21SL |
| Depth | 1.25mm |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Operating Frequency | 50MHz |
| Series | NFA21SL |
| Maximum Operating Temperature | 125°C |
| Capacitance | 80pF |
| Minimum Operating Temperature | -55°C |
| Maximum Current | 20mA |
| Maximum Voltage | 10V dc |
| Standards/Approvals | RoHS |
| Package/Case | 0805 |
| Termination Style | Solder |
Key Features
- 10V DC maximum voltage for reliable electronic circuit protection.
- 50MHz rated operating frequency ideal for EMI suppression at signal and power lines.
- 20mA maximum current handling in a compact 0805 package.
- Surface mount design with solder termination for quick and efficient PCB assembly.
- RoHS compliant for environmentally responsible manufacturing.
- Suitable for personal computers, communications, telephones, digital TV, and other electronic devices.
Product Description
The Murata NFA21SL506X1A48L EMI Filter is a high-performance surface mount component designed for effective electromagnetic interference suppression in electronic circuits. With a rated maximum voltage of 10V DC and an operating frequency up to 50MHz, this filter ensures stable noise attenuation is achieved across a wide frequency range, making it particularly suitable for digital I/O lines and sensitive signal paths.
Engineered in a compact 0805 package, the filter offers a maximum current capability of 20mA and features solder terminals for easy PCB integration. Its small footprint - measuring just 2mm in length, 1.25mm in depth, and 0.85mm in height - enables efficient circuit design without compromising space requirements. The certified RoHS compliance indicates environmentally conscious production and material usage.
Leveraging Murata’s advanced ceramic processing and filter design technology, the NFA21SL506X1A48L provides reliable EMI suppression and prevents ringing due to circuit impedance mismatches. The component is well suited for applications such as personal computers, communications equipment, telephones, and digital TVs where signal integrity and noise control are essential.
With robust operational temperature range from -55°C up to 125°C, this filter maintains performance under varying environmental conditions. Its capacitance rating of 80pF further contributes to attenuation of unwanted signals and line noise.
This product is frequently used on PCB mount configurations (SMT) for signal/line/noise and feedthrough filtering. Packaging is in tape & reel for automated production environments, and the country of origin is Japan, exemplifying Murata’s commitment to quality.
Effective suppression of EMI across a wide frequency spectrum for digital and analog lines. Advanced ceramic technology and stable attenuation characteristics. Designed for low-profile installations due to its minimal size.
Temperature resilient for both consumer and industrial electronics. RoHS certified and suitable for environmentally aware production cycles. Discover more surface mount filters and EMI suppression solutions in the Electronics & Electricals category from Murata on EnvMart.
Explore more products in our EMI Filters category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating of this EMI filter is 10V DC.
This model operates at a frequency of up to 50MHz, making it suitable for effective EMI suppression.
The maximum current handling capacity of this filter is 20mA.
The dimensions of this filter are 2mm in length, 1.25mm in depth, and 0.85mm in height.
It features solder termination, allowing for easy integration into PCB designs.
The capacitance rating of this filter is 80pF, which aids in the attenuation of unwanted signals.
The product is packaged in tape & reel, which is suitable for automated production environments.
This filter operates within a temperature range of -55°C to 125°C.
Yes, this EMI filter is RoHS compliant, indicating environmentally responsible manufacturing.
It is suitable for applications in personal computers, communications equipment, telephones, and digital TVs.
The NFA21SL EMI filter is manufactured in Japan.
This model is designed for surface mount applications.
