Schneider Electric LC1K Contactor, 230V AC Coil, 3-Pole, 9A, 4kW 230V AC, 3 NO Auxiliary Contacts LC1K0910P7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 58mm |
| Model | LC1K0910P7 |
| Depth | 57mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, RoHS, IEC, EAC, CSA, CCC |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NO |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 230V ac |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running |
| Example of use | all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Compact design allowing DIN rail or panel mounting.
- Includes one built-in normally open (NO) auxiliary contact.
- Designed for control circuits compatible with 50Hz and 60Hz supplies.
- Touch-proof IP20-rated front face protects against accidental contact.
- Wide operating temperature range from -25°C to 50°C.
- Rated for 4 kW at 230V AC, suitable for simple motor applications.
- Equipped with screw clamp terminals with international terminal markings.
- Complies with international standards including UL, IEC, CSA, CCC, and RoHS.
Product Description
Schneider Electric LC1K0910P7 is a compact and highly reliable 3-pole contactor designed for motor control and resistive load applications. Featuring a 230V AC coil and a 9A contact current rating, it supports power loads up to 4 kW at 230V AC. This contactor is engineered with an IP20-rated touch-proof front face to ensure safety during operation and maintenance.
Its compact dimensions (45mm width, 58mm length, 57mm depth) allow for easy integration in DIN rail and panel mounting setups. The device comes with one built-in normally open (NO) auxiliary contact, simplifying system expansions and control functions.
The LC1K0910P7 contactor supports operational environments ranging from -25°C to 50°C. Screw clamp terminals provide secure and straightforward wiring, compatible with both North American and International terminal markings, facilitating global installations.
Certified under multiple international standards including UL, IEC, CSA, CCC, and RoHS, this contactor aligns with strict quality and environmental requirements. Manufactured in France, it is optimized for a reduced carbon footprint and end-of-life disassembly.
Typical applications include motor-driven equipment in industrial automation, food and beverage processing, agricultural machinery, healthcare facilities, and airport infrastructure. It is well-suited for managing resistive and motor loads, providing dependable control in demanding environments.
Compact design allowing DIN rail or panel mounting. Includes one built-in normally open (NO) auxiliary contact. Designed for control circuits compatible with 50Hz and 60Hz supplies. Touch-proof IP20-rated front face protects against accidental contact.
Wide operating temperature range from -25°C to 50°C. Rated for 4 kW at 230V AC, suitable for simple motor applications. Equipped with screw clamp terminals with international terminal markings. Complies with international standards including UL, IEC, CSA, CCC, and RoHS.
Made in France with environmental considerations such as designed for disassembly.
Explore other compatible auxiliary contact blocks (LA1K, LA2K) and thermal relay options (LR2K) to enhance system functionality. Shop and browse quality contactors like the Schneider Electric LC1K0910P7 in the Contactors category at EnvMart for reliable automation and control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1K0910P7 contactor has a power rating of 4 kW at 230V AC.
This model is rated for a maximum contact current of 9A.
The dimensions of this contactor are 45mm in width, 58mm in length, and 57mm in depth.
It supports DIN rail mounting as well as panel mounting.
The coil voltage for the LC1K0910P7 is 230V AC.
It can operate in environments ranging from -25°C to 50°C.
This contactor includes one built-in normally open (NO) auxiliary contact.
It features an IP20-rated touch-proof front face to protect against accidental contact.
It complies with multiple international standards including UL, IEC, CSA, CCC, and RoHS.
It is suitable for motor control and resistive load applications, including industrial automation and healthcare facilities.
It is equipped with screw clamp terminals that have international terminal markings.
The normal state configuration of the contacts is 3 normally open (NO).
