HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 14 Contacts, 2 mm Pitch, 2 Row, Shrouded M80-8511442

HARWIN M80-8511442 Datamate L-Tek Series Right Angle Through Hole PCB Header is a high reliability connector designed for severe conditions requiring secure and durable PCB connections. Featuring 14 male contacts spaced at a 2 mm pitch across two rows, this shrouded header ensures proper alignment and protection against mis-mating.

The housing material, polyphenylene sulphide, offers excellent mechanical strength and heat resistance, suitable for tough industrial environments. Contacts are made from phosphor bronze with a gold plating, guaranteeing superior electrical performance and corrosion protection over many mating cycles.

This PCB header supports board-to-board and wire-to-board connector systems with a right angle orientation, making it ideal for complex electronic assemblies where space optimization is critical. The solder termination type with a 3 mm tail pin length facilitates secure PCB mounting.

The product is rated for 3A current at 120V, operating reliably within a thermal range of -55°C to 125°C. The shrouded design and polarised mouldings help maintain connection integrity, especially in applications subject to vibration, shock, or acceleration.

Compliant with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards, this header meets demanding reliability criteria. It is suited for industrial manufacturing, electronic equipment assembly, aerospace, and other professional sectors requiring robust PCB connectors.

The connector system supports both board-to-board and wire-to-board applications. Housing is made from durable polyphenylene sulphide ensuring stability in harsh environments. Gold-plated phosphor bronze contacts provide excellent conductivity and corrosion resistance.

Rated for 3A current and 120V voltage for reliable electrical performance. Designed for solder termination with a tail pin length of 3 mm and right angle orientation. Operates safely within a temperature range of -55°C to 125°C.

Shrouded design with polarised mouldings enhances connection integrity and durability. Suitable for industrial, electronic manufacturing, and COTS applications. Manufactured in the United Kingdom to high reliability standards.

This HARWIN Datamate L-Tek Series header is essential for reliable PCB interconnections in electronic components and assemblies. Explore more high quality PCB Headers and connectors in the Electronics Components category at EnvMart.
