HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 4 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8430442

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 4 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8430442

Name: HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 4 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8430442
Brand: HARWIN
SKU: 122840



Category PCB Headers Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Right Angle
Current	3A
Model	M80-8430442
Mount Type	Through Hole
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3mm

Key Features

Durable polyphenylene sulphide housing suitable for harsh environments.
Supports 3 Ampere current with high conductivity gold-plated phosphor bronze contacts.
Right-angle shrouded design for secure and space-saving PCB connections.
Operates reliably from -55°C to 125°C temperature range.
Tail pin length of 3 mm ensures secure solder termination.
Compatible with board-to-board and wire-to-board connector systems.
Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards.

Product Description

HARWIN M80-8430442 Datamate L-Tek Series Right Angle Through Hole PCB Header is engineered for durability and reliability in demanding electronic applications. Featuring 4 contacts arranged in a single row with a 2 mm pitch, this shrouded header ensures secure connections and prevents accidental misalignment.

Constructed with a robust polyphenylene sulphide housing, this PCB header withstands harsh environments and heavy usage with high resistance to vibration and shock. The gold-plated phosphor bronze contacts include a four-finger beryllium copper design, enhancing connection integrity even under severe conditions.

The right-angle orientation and 3 mm tail pin length permit efficient PCB mounting, facilitating board-to-board and wire-to-board applications. Operating voltage is rated at 120V with a maximum current of 3A, suitable for various industrial and commercial electronic assemblies.

This header complies with standards including BS9525-F0033, MIL C 55302, and CEC 75101-008, confirming its suitability for safety-conscious and harsh environment uses. The connector housing material is polyphenylene sulphide providing excellent thermal and mechanical performance.

Contact plating with gold ensures high corrosion resistance and low contact resistance. Tail pin length of 3 mm supports reliable solder terminations. Operating temperatures range from -55°C to 125°C allowing use in diverse environmental conditions.

Provides board-to-board and wire-to-board connectivity solutions in multiple industries. Shrouded design improves connector polarization and mechanical protection. Right-angle design enables space-saving PCB layouts and assembly flexibility.

This product is manufactured in the United Kingdom and offered in a new, unused condition. It caters to electronics manufacturing, industrial automation, aerospace, and other sectors requiring robust PCB connectors.
