Nexperia 8.2 V 1.3 W Single Zener Diode Through Hole 2-Pin DO-41 BZV85-C8V2,113

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 8.2 V 1.3 W Single Zener Diode Through Hole 2-Pin DO-41 BZV85-C8V2,113

Name: Nexperia 8.2 V 1.3 W Single Zener Diode Through Hole 2-Pin DO-41 BZV85-C8V2,113
Brand: Nexperia
SKU: 122647
Price: 0.07 USD
Availability: InStock



Category Zener Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	2.6mm
Length	4.8mm
Model	BZV85-C8V2,113
Mount Type	Through Hole
Series	BZV85
Maximum Operating Temperature	200°C
Package Type	DO-41
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	1.3W
Diode Configuration	Single
Test Current It	25mA
Maximum Reverse Leakage Current	700nA
Nominal Zener Voltage Vz	8.2V
Zener Type	Voltage Regulator
Maximum Zener Impedance	5Ω
Typical Voltage Temperature Coefficient	4.6mV/°C

Key Features

This Zener diode has a nominal zener voltage of 8.2 V with a tolerance of ±5%.
It features a single diode configuration suitable for voltage regulation.
The package type is DO-41 with a through-hole mount and two pins.
The maximum power dissipation capability is 1.3 watts.
The diode can operate between -65°C and 200°C ambient temperatures.
Maximum reverse leakage current is 700 nA ensuring low leakage.
Typical zener impedance is 5 ohms, optimizing voltage regulation stability.
The diode has a test current of 25 mA and a voltage temperature coefficient of 4.6 mV/°C.

Product Description

Nexperia BZV85-C8V2,113 is a high-quality single Zener diode designed for voltage regulation applications with a nominal voltage of 8.2 V and power dissipation up to 1.3 W. Packaged in a durable DO-41 through-hole package with 2 pins, it is engineered to provide reliable performance in various industrial, electronic, and instrumentation circuits.

The diode configuration is single with a voltage regulator Zener type, ideal for protecting circuits from voltage spikes and ensuring voltage stabilization across a range of operating temperatures from -65°C to 200°C. It features a low maximum reverse leakage current of 700 nA which minimizes power loss and enhances circuit efficiency.

With a test current of 25 mA and a maximum Zener impedance of 5 ohms, the BZV85-C8V2,113 offers excellent voltage regulation stability. The typical zener voltage temperature coefficient of 4.6 mV/°C ensures predictable voltage behavior under changing temperature conditions. Its compact dimensions of 4.8 mm length and 2.6 mm height allow easy integration on printed circuit boards using through-hole technology.

The device conforms to industry standards but is specified with no formal approvals or automotive standard compliance. Originating from China, this product is ideal for applications in industrial electronics, communication devices, laboratory equipment, and power management systems.

This product is a new and unused Nexperia Zener diode, BZV85 series. Set contains 1 single-piece diode in a DO-41 package with through-hole mount. Explore more Zener Diodes and related semiconductor components in the Electronics & Electricals category at EnvMart for your next industrial or commercial project.
