Eaton xPole Miniature Circuit Breaker, 1-Pole, 20A, Type D, 400V AC, 48V DC, 10 kA Breaking Capacity 236101 PXL-D20/1
Specifications
| Country of Origin | Austria |
|---|---|
| Range | xPole |
| Brand | Eaton |
| Height | 17.5mm |
| Model | 236101 PXL-D20/1 |
| Depth | 60mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | PXL |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | EN 60898, IEC |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Designed for DIN Rail mounting ensuring easy installation.
- Compatible with bus bars and features double terminals for secure connections.
- Supports rated voltages of 400 V AC and 48 V DC for versatile electrical applications.
- Offers instantaneous break time for fast disconnection during fault conditions.
- Equipped with a toggle switch reset actuator for user-friendly operation.
- Compliance with IEC and EN 60898 standards for safety and reliability.
- Compact dimensions of 80mm width, 17.5mm height, and 60mm depth save panel space.
- IP20 rated for finger and back-of-hand protection, enhancing operator safety.
Product Description
Eaton 236101 PXL-D20/1 Miniature Circuit Breaker is a high-quality electrical protection device designed for industrial and commercial use, offering reliable circuit interruption for low-voltage installations. It features a type D tripping characteristic suitable for applications with transient overcurrent conditions, making it ideal for protecting sensitive electrical equipment.
This 1-pole breaker has a current rating of 20 amperes and supports rated voltages of 400 volts AC and 48 volts DC. Its breaking capacity of 10 kiloamperes ensures the device can safely interrupt high fault currents, protecting wiring and connected devices from damage.
The breaker is designed for easy DIN rail mounting, compatible with bus bars, and includes double terminals with lift/jaw top and bottom connections for secure wiring. Its compact size with a width of 80 mm, height of 17.5 mm, and depth of 60 mm allows efficient use of panel space.
It features an instantaneous break mechanism for rapid disconnection in fault conditions, and is equipped with a toggle switch reset actuator for straightforward manual operation. The IP20 rating provides finger and back-of-hand protection, adhering to stringent safety norms.
Manufactured in Austria under strict IEC and EN 60898 quality standards, this circuit breaker is suitable for various industrial, commercial, and electrical automation applications requiring dependable short circuit and overload protection.
Reliable type D tripping characteristic for selective protection. Rated for 20A current, 400V AC, and 48V DC operation. High breaking capacity of 10 kA for robust fault current handling. Compact and user-friendly design with toggle reset actuator.
Compliance with IEC and EN standards ensuring safety and durability. IP20 rating for enhanced operator safety. Ideal for industrial, electrical automation, and commercial panel installations. DIN rail mountable with bus bar compatibility for versatile wiring.
Manufactured in Austria with premium build quality. For a comprehensive range of circuit breakers and electrical protection devices, explore the Eaton products and related solutions available at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 20 amperes.
It supports rated voltages of 400 volts AC and 48 volts DC.
The breaking capacity is 10 kiloamperes, allowing it to safely interrupt high fault currents.
This unit features a Type D tripping characteristic, suitable for applications with transient overcurrent conditions.
It is designed for DIN rail mounting, ensuring easy installation.
The dimensions are 80 mm in width, 17.5 mm in height, and 60 mm in depth.
It has an IP20 rating, providing finger and back-of-hand protection.
It is equipped with a toggle switch reset actuator for user-friendly operation.
It complies with IEC and EN 60898 standards for safety and reliability.
This model features an instantaneous break time for rapid disconnection during fault conditions.
It is manufactured in Austria.
This miniature circuit breaker has 1 pole.
