Eaton xPole Miniature Circuit Breaker, 2-Pole, 13A, Type C, 400V AC, 48V DC, 10 kA Breaking Capacity 236287 PXL-C13/2

Eaton 236287 PXL-C13/2 Miniature Circuit Breaker is a robust electrical protection device designed for industrial and commercial applications requiring precise circuit interruption and overload protection. With a current rating of 13A and Type C tripping characteristic, it offers rapid response to short circuits while minimizing nuisance trips in equipment sensitive to transient surges.

This 2-pole circuit breaker supports an AC voltage rating of 400V and a DC voltage rating of 48V, making it suitable for a wide range of electrical installations. Its breaking capacity of 10 kA ensures safe disconnection under high fault current conditions, protecting downstream circuitry and preventing damage.

The device is built for convenient installation on a DIN rail, featuring a quick-fit mechanism with three locking positions compliant with IEC / EN 60715 standards. The double terminal design facilitates secure wiring connection both from top and bottom, enhancing installation flexibility.

Equipped with an electromagnetic tripping mechanism and a toggle switch for easy reset, the breaker is engineered to provide reliable operation with fast trip times indicated by its instantaneous break time. Its finger-proof and back-of-hand-proof design ensures user safety during operation and maintenance.

Compact in size with dimensions of 80mm width, 35mm height, and 60mm depth, the breaker integrates seamlessly into panel boards and electrical enclosures without occupying excessive space.

Designed for DIN rail mounting with high selectivity. Supports AC voltage up to 400V and DC voltage up to 48V. Features quick-fit action with 3 locking positions on top-hat rail IEC / EN 60715. Equipped with electromagnetic tripping mechanism and toggle switch reset actuator.

Constructed with double terminals and finger-proof design for safety. Complies with IEC 60898 and EN 60898 standards. Compact dimensions: 80mm width, 35mm height, 60mm depth. Manufactured in Austria ensuring quality and reliability.

This Miniature Circuit Breaker is ideal for applications in industrial control panels, electrical distribution boards, automation systems, and commercial installations where precise overload and fault current protection is required. Eaton's xPole PXL series is recognized for dependable performance and ease of integration in diverse electrical systems.
