Jaeger Circular Connector, 3 Contacts, Miniature Cable Socket, Female, IP65, Aluminium Housing, Push Pull 5302 320 06

Jaeger 5302 320 06 Circular Connector is a high-quality miniature cable socket designed to provide secure and efficient electrical connections in industrial environments. Constructed from nickel-plated aluminium, the housing ensures durability and resistance to environmental factors, while the gold-plated brass contacts deliver excellent conductivity and corrosion resistance.

This female socket is designed with 3 contacts arranged in a straight orientation and terminated using screws for reliable and maintenance-friendly installation. The 5302 series connectors utilize a push-pull mating mechanism that allows quick and secure locking, minimizing downtime during assembly or servicing.

With an IP65 rating, this connector offers protection against dust and water jets, making it well-suited for harsh industrial, manufacturing, automation, and machinery applications. It supports electrical loads up to 7A and operates at voltages up to 2500V, fulfilling the demands of power and signal transmission in industrial control systems.

Operating reliably within a temperature range of -40°C to 100°C, this connector can withstand challenging thermal conditions. Its compact B00 shell size ensures space-efficient mounting in panels or equipment housings.

As per the product standards, this connector does not carry specific approvals but is designed for robust industrial usage. The connector series also supports the use of specialized tools such as tool ref. 5971 040 06 for fitting and removal of contacts, ensuring ease of maintenance.

Robust aluminium shell with nickel plating for durability. Gold-plated brass contacts ensure excellent electrical performance. Push-pull locking mechanism for secure and fast mating. Cable mount type with screw termination for solid attachment.

IP65 rated for protection against dust and water jets. Rated for 7A current and 2500V maximum voltage. Operates from -40°C to 100°C to suit harsh environments. Miniature B00 size for compact installation. Manufactured in France with high-quality standards.

This circular connector is ideal for use in industrial automation, manufacturing, control panels, and machinery where reliable connections and rugged design are critical. The 5302 series offers versatile options with compatibility extending to plugs and accessories for tailored connectivity solutions.
