Wurth Elektronik Multilayer Ceramic Capacitor 100pF 100V DC ±5% Surface Mount 0805 CSGP 885012007082

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik Multilayer Ceramic Capacitor 100pF 100V DC ±5% Surface Mount 0805 CSGP 885012007082

Name: Wurth Elektronik Multilayer Ceramic Capacitor 100pF 100V DC ±5% Surface Mount 0805 CSGP 885012007082
Brand: Wurth Elektronik
SKU: 115242
Price: 0.05 USD
Availability: InStock



Category Multilayer Ceramic Capacitor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	100V dc
Brand	Wurth Elektronik
Height	0.6mm
Length	2mm
Packaging	Tape & Reel
Width	1.25mm
Mount Type	Surface
Construction	Stacked
Series	CSGP
Termination Type	Solder
Maximum Operating Temperature	125°C
Tolerance	±5 %
Capacitance	100pF
Minimum Operating Temperature	-55°C
Standards/Approvals	EC, IEC, JEDEC JS709B, REACH, RoHS
Package/Case	0805
Dielectric	C0G
Suppression Class	Class II

Key Features

This capacitor operates with a capacitance of 100pF and voltage rating of 100V DC.
The package size is 0805 with a stacked construction design.
Dielectric material is temperature stable C0G class, ensuring minimal aging and high reliability.
The capacitor is designed for surface mounting with solder termination type.
Operating temperature ranges from -55°C to 125°C, suitable for demanding environments.
Tolerance is ±5%, supporting precise circuit requirements.
Packaging is on tape and reel, enabling efficient automated assembly.
Standards compliance includes EC, IEC, JEDEC JS709B, REACH, and RoHS directives.

Product Description

Wurth Elektronik 885012007082 is a high-quality 100pF Multilayer Ceramic Capacitor designed for surface mount application in electronic circuits requiring stable capacitance and precision.

This capacitor is constructed with a stacked design and uses a C0G temperature stable dielectric material which allows minimal aging and excellent electrical stability, making it ideal for filtering, coupling, bypass, and temperature compensation applications.

The device is rated for 100V DC voltage with ±5% tolerance and can operate reliably between -55°C and 125°C, ensuring robust performance under varying environmental conditions. Encased in an industry standard 0805 package size, it facilitates high-volume assembly via tape and reel packaging and solder termination.

With dimensions of 2mm length, 1.25mm width, and 0.6mm height, it fits compact electronic designs in sectors such as industrial electronics, telecommunications, automotive electronics, and consumer devices.

This capacitor provides high electrical precision and stability with minimal aging. Uses temperature stable C0G dielectric for wide temperature range applications. Complies with major industry standards including EC, IEC, JEDEC JS709B, REACH, and RoHS.

Available in tape and reel packaging suitable for automated production lines. Surface mount type with solder terminations enables reliable PCB assembly. Ideal for industrial, laboratory, telecommunications, automotive, and electronics manufacturing sectors requiring dependable passive components.
