TE Connectivity Surface Monostable Relay 4.5V DC Coil 6A Switching Current DPDT 9-1462038-8
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 15mm |
| Length | 20mm |
| Width | 10mm |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 6A |
| Terminal type | Solder |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS, UL |
| Coil Resistance | 100Ω |
| Coil Voltage | 4.5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 400mW |
Key Features
- Designed for surface mount applications with gull wing terminals for easy soldering.
- Operates within temperature range of -40°C to 85°C for versatile industrial use.
- Switches up to 30V DC and 250V AC, suitable for power relay applications.
- Uses silver alloy contact material ensuring durability and low contact resistance.
- Features coil resistance of 100 Ω and coil power rating of 400 mW for low energy consumption.
- Compact dimensions of length 20 mm, width 10 mm, and height 15 mm optimize PCB space.
- Compliant with RoHS and UL standards ensuring high regulatory compliance.
- Contact resistance is 50 mΩ offering efficient power flow with minimal losses.
Product Description
TE Connectivity 9-1462038-8 Surface Monostable Relay is a high-quality DPDT relay designed for precise control of electrical circuits. It operates with a 4.5V DC coil voltage and can switch currents up to 6A, making it ideal for power relay applications in electronics and electrical industries.
Its surface-mount design with gull wing terminals allows for efficient soldering onto PCBs, delivering reliable and compact solutions for signal conditioning and power control. The relay uses durable silver alloy contacts, providing low resistance contact points measured at 50 milliohms, ensuring minimal energy loss and excellent conductivity.
With operating temperatures ranging from -40°C to 85°C, it is suitable for harsh environmental conditions encountered in industrial, HVAC, manufacturing, and automation sectors. The relay’s coil resistance is 100 ohms, with a low coil power consumption of 400 milliwatts, contributing to energy efficiency.
The compact dimensions of 20 mm length, 10 mm width, and 15 mm height optimize board space utilization. This relay complies with RoHS and UL certifications, confirming it meets stringent safety and environmental standards.
Typical use cases include electrical circuit control, signal switching, industrial automation systems, and power relay functions in various industrial and commercial equipment. Its dual-pole double-throw (DPDT) contact configuration allows for versatile switching applications requiring multiple circuit controls.
Designed for surface mount applications with gull wing terminals for easy soldering. Operates within temperature range of -40°C to 85°C for versatile industrial use. Switches up to 30V DC and 250V AC, suitable for power relay applications.
Uses silver alloy contact material ensuring durability and low contact resistance. Features coil resistance of 100 Ω and coil power rating of 400 mW for low energy consumption. Compact dimensions of length 20 mm, width 10 mm, and height 15 mm optimize PCB space.
Compliant with RoHS and UL standards ensuring high regulatory compliance. Contact resistance is 50 mΩ offering efficient power flow with minimal losses. Explore more high-performance power Relays and reliable components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay can switch currents up to 6A.
It operates with a coil voltage of 4.5V DC.
The relay has compact dimensions of 20 mm in length, 10 mm in width, and 15 mm in height.
It features a dual-pole double-throw (DPDT) contact configuration.
It operates within a temperature range of -40°C to 85°C.
This model has gull wing terminals designed for surface mount applications.
The contact resistance is 50 milliohms, ensuring efficient power flow.
The relay features a coil resistance of 100 ohms and a coil power rating of 400 milliwatts.
It can switch up to 30V DC and 250V AC.
The contacts are made of silver alloy, which ensures durability and low contact resistance.
Yes, it is compliant with RoHS and UL standards.
It is suitable for electrical circuit control, signal switching, and industrial automation systems.
