Schurter Non-Resettable Fuse 5A, 125 V AC, 125 V DC Fast Acting Thermoplastic Body 3404.0017.11
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 125, 125V ac |
| Brand | Schurter |
| Body Material | Thermoplastic |
| Height | 2.6mm |
| Depth | 7.4mm |
| Series | OMF 125 |
| Maximum Operating Temperature | 125°C |
| Package Type | Plastic Bag |
| Minimum Operating Temperature | -55°C |
| Breaking Capacity | 100A |
| Terminal Material | Tin Plated Copper |
| Standards/Approvals | CSA, UL 248-14, CE, RoHS, REACH |
| Fuse Characteristics | Fast Acting |
| Littelfuse SMD Non Resettable Fuse 5A, 32VBrand | Littelfuse |
Key Features
- The fuse body is made from durable UL94V-0 rated thermoplastic.
- It is suitable for all SMD soldering processes and surface mount technology.
- The fuse features tin-plated copper terminals for reliable electrical conduction.
- It has a breaking capacity of 100A ensuring robust circuit protection.
- Operates within temperature range of -55°C to 125°C for versatile environments.
- Ideal for protecting high value silicon ICs in alarm systems and power supplies.
- Complies with UL, CSA, CE, RoHS, and REACH standards for quality assurance.
- Compact dimensions of 2.6 mm height and 7.4 mm depth enable space saving in circuit boards.
Product Description
Schurter 3404.0017.11 Non-Resettable Fuse is engineered as a fast acting fuse with a voltage rating of 125 V AC and 125 V DC, designed to provide reliable overcurrent protection in compact electronic circuits.
The fuse body is constructed using UL94V-0 rated thermoplastic material, giving it excellent flame retardant properties suitable for demanding industrial and commercial applications.
Featuring tin-plated copper terminals, it ensures optimal conductivity and compatibility with surface mount technology for efficient soldering and circuit assembly processes.
The fuse offers a high breaking capacity of 100A, which makes it suitable for use in protecting sensitive electronic components such as high value silicon ICs found in alarm systems, audio/visual equipment, computer boards, portable telephones, power supplies, and medical apparatus.
Designed to operate in environments from -55°C up to 125°C maximum temperature, this fuse remains reliable under extreme conditions.
The compact size, with a height of 2.6 mm and depth of 7.4 mm, allows for significant space savings on circuit boards, especially when used in surge protection and low voltage applications.
This fuse complies with key international standards including UL recognized component status, CSA certification, CE marking, RoHS, and REACH regulations, ensuring quality and environmental safety.
The fuse body is made from durable UL94V-0 rated thermoplastic. It is suitable for all SMD soldering processes and surface mount technology. The fuse features tin-plated copper terminals for reliable electrical conduction.
It has a breaking capacity of 100A ensuring robust circuit protection. Operates within temperature range of -55°C to 125°C for versatile environments. Ideal for protecting high value silicon ICs in alarm systems and power supplies.
Complies with UL, CSA, CE, RoHS, and REACH standards for quality assurance. Compact dimensions of 2.6 mm height and 7.4 mm depth enable space saving in circuit boards. This product is primarily suited for industrial electrical, automation, manufacturing, and commercial electronics applications requiring high 안전성 and dependable fuse technology.
Explore more Schurter electrical protection components and Fuses at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The fuse has a voltage rating of 125 V AC and 125 V DC.
It has a breaking capacity of 100A, providing robust circuit protection.
The fuse has a height of 2.6 mm and a depth of 7.4 mm, allowing for compact installation on circuit boards.
This model operates within a temperature range of -55°C to 125°C, making it suitable for various environments.
The fuse body is made from UL94V-0 rated thermoplastic, and it features tin-plated copper terminals for reliable electrical conduction.
It complies with UL, CSA, CE, RoHS, and REACH standards, ensuring quality assurance and environmental safety.
Yes, it is suitable for all SMD soldering processes and surface mount technology.
This fuse is ideal for protecting high value silicon ICs in alarm systems, audio/visual equipment, computer boards, portable telephones, power supplies, and medical apparatus.
It is classified as a fast acting fuse, providing quick response to overcurrent conditions.
The fuse is packaged in a plastic bag for convenience and protection during storage and transport.
The country of origin for this fuse is Switzerland.
This model belongs to the OMF 125 series, which is designed for specific applications in electronic circuits.
