Bourns Shielded Wirewound Surface Mount Inductor, 10 μH ±20 %, 10 A Idc, Carbonyl Powder Core, 1265 Package SRP1265A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 6.2mm |
| Length | 13.5mm |
| Model | SRP1265A |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | SRP1265A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Carbonyl Powder |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | 1265 |
| Maximum DC Current | 10A |
| Pin Count | 2 |
| Maximum DC Resistance | 16.5mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 10MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a carbonyl powder core for high performance and shielding.
- Wirewound inductor design delivering low DC resistance of 16.5 mΩ.
- Package size 1265 with dimensions 13.5mm length, 12.5mm depth, and 6.2mm height.
- RoHS compliant and Automotive AEC-Q200 qualified for reliable automotive system application.
- Operating temperature range from -40°C to 150°C supporting harsh environments.
- Offers a high-quality factor (Q) of minimum 20 at resonance.
- Maximum self-resonant frequency up to 10 MHz for stable operation.
- Termination style is solder suitable for surface mount technology.
Product Description
Bourns SRP1265A shielded wirewound surface mount inductor is engineered with a carbonyl powder core to provide outstanding electromagnetic shielding and high saturation current handling capability. It features a nominal inductance of 10 μH with ±20 % tolerance and supports a maximum DC current of 10 A, making it ideal for high current power electronics.
Designed in a 1265 package with compact dimensions (13.5mm length x 12.5mm depth x 6.2mm height), this inductor is suitable for surface mount assembly with solder termination. Its low DC resistance of 16.5 mΩ helps improve efficiency by minimizing power loss.
The product meets RoHS compliance and is Automotive AEC-Q200 qualified, ensuring reliability in automotive electronics such as driver assistance, information systems, entertainment, and lighting controls. Operating temperature range from -40°C to 150°C allows usage in harsh environmental conditions.
The inductor achieves a high minimum quality factor (Q) of 20, and a maximum self-resonant frequency of 10 MHz, providing stable frequency response in switching power supplies and DC-DC converters.
Constructed with a carbonyl powder core for enhanced performance and shielding. Wirewound surface mount configuration for compactness and durability. Suitable for automotive and industrial electronic systems. Low DC resistance ensures energy efficient operation.
Compliant with RoHS and automotive standard AEC-Q200. Temperature tolerant from -40°C to 150°C for varied environmental conditions. High quality factor and frequency stability for power supply applications.
This Bourns SRP1265A inductor supports industrial, automotive, and manufacturing electronics requiring robust electromagnetic interference suppression and efficient power handling. Explore more Surface Mount Inductors on EnvMart to find compatible components for your designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 10 μH with a tolerance of ±20%.
It supports a maximum DC current of 10 A, making it suitable for high current applications.
This unit has dimensions of 13.5 mm in length, 12.5 mm in depth, and 6.2 mm in height.
The maximum operating temperature is 150°C, allowing it to function in harsh environments.
It achieves a minimum quality factor (Q) of 20 at resonance, ensuring stable operation.
The maximum self-resonant frequency is up to 10 MHz, providing stable frequency response.
This inductor is constructed with a carbonyl powder core, enhancing its performance and shielding.
The termination style is solder, suitable for surface mount technology.
Yes, it is RoHS compliant and qualified under the Automotive AEC-Q200 standard.
The DC resistance is 16.5 mΩ, which helps improve efficiency by minimizing power loss.
It is suitable for automotive and industrial electronic systems requiring electromagnetic interference suppression and efficient power handling.
The country of origin for this model is India.
